Electric Cutting 17 Stations 17.7kw K Span Machine For Roof

Electric Cutting 17 Stations 17.7KW Large Span Roof Panel Roll Forming Machine 45# Steel

Main Specifications Of Large Span Roof Panel Roll Forming Machine

Thickness of sheet: 0.8-1.5mm

• Mounting dimension of Large Span Roll Forming Machine: 8900mmx2250mmx2300mm
• Total weight: about 13 Ton
• Forming Station: 17 stations
• Control system: electric control
• Main motor power: 17.7KW
• Forming Power is 7.5KW
• Curving motor power: 4KW
• Electric cutting motor power: 4kw
• Conical Power is 2.2KW
• Material of rollers: 45# steel, quenched HRC58-62
• Material of shaft: 45# steel, adjusted
• Material of cutting blade: Cr12 steel
• Quenching hardness: HRC58-60

Technical Details

Cangzhou Best Machinery Co., Ltd set up in 2015, with great power in production and techniques, we are a leading manufacturer of roll forming machines in North of China.We have two workshops more than 4000 square meters, and have own processing machines and design engineer, so that can control machine production time and quality;Our factory is near Beijing or Tianjing, and in Cangzhou there is railway station, so it is convinent transport.Welcome to visit our factory anytime.

Our main products are CUSTOMIZED ROLL FORMING MACHINES, because clients will use roll forming machines instead of bending machine or pressing machines to save labor, and improve production, our regular products are roof sheet roll forming machine, roof tile roll forming machine, CZ roll forming machine, floor decking roll forming machine, highway guardrail roll forming machine, cable tray roll forming machine, stud and track roll forming machine, door roll forming machine, slitting and cut to length, sandwich panel machine and so on.

We have advanced production equipment and our engineering personnel and technicians have extensive experience in designing, developing, and manufacturing machineries. They pay close attention to and keep up with the developing trend of technologies and use new technologies in manufacturing machinery, to keep them competitive. Our products feature high efficiency, high flexibility and low cost.

"Customers are the first, success comes from development" is our principle. We bear this in mind during the whole process from design and development of product to after-sales services. We will design and manufacture machinery strictly in accordance with your requirements.

With good after-sales service network, we can provide support covering the whole process of purchasing, which help you get perfect machinery. We'll solve all the problems you have while using the machines and we'll provide considerate services.

Our machines have been sold to North America, like US, Canada, South America, Nicaragua, Peru, Brazil, Bolivia, Uruaguy, Argentina, Europe, like Greece, Middle east, like Saudi Arab, Dubai, Iran, Iraq, Africa, Egypt, Ghana, Nigeria, Ethiopia, Malawi, Kenya, Tanzania, Zambia, Zimbabwe, South Africa, Australia, New Calidonia, Asia, India, Thailand, Philippines, Indonesia, Papua New Guinea, Bangladesh, Pakistan, Turkmenistan, Malaysia, Vietnam, Mongolia, helping us enter the international market.

Excellent service and high technology assist you to create a bright future.

To make sure machine quality, we applied CE certificate and SGS certificate and so on.



Our roll froming machine exported all over the world and win good repution,clients give good feedback,we have been exported to more than 120 countries and regions in the world, including: Germany, Japan, Italy, Russia, Japan, South Korea, Turkey, Brazil , India, the United Arab Emirates, Saudi Arabia and other countries, the products are subject to a great welcome and praise. INDIA, AFRICA, SOUTH AMERICA.

WE WILL YOUR BEST SUPPLIER IN CHINA,WELCOME TO CONTACT US.
