| Categories | Hercules Seal Kit |
|---|---|
| Brand Name: | SUNCAR |
| Model Number: | D9691500 Breaker seal kit |
| CertifiC-A-Tion: | ISO9001 |
| Place of Origin: | CN |
| MOQ: | Accept trial order |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, |
| Supply Ability: | 550 Sets Per Week. |
| Delivery Time: | 3-7 Days After Payment Received(Public Holiday Excluded) |
| Packaging Details: | PP Bag Inside,Carton Box Outside. |
| Brand: | SUNCAR |
| Type: | Breaker seal kit |
| Part number: | D9691500 |
| Model: | HK200 |
| Working medium: | Hydraulic oil, gas,water, etc |
| Material: | PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Features: | Oil resistance, Heat resistance, Durable, Sealing Performance, Manufacture |
| AppliC-A-Tion: | Breaker;Resell store;Construction machinery works |
| Feature: | High efficiency, Long life |
| Style: | Excavator seal kit |
| Company Info. |
| GUANGZHOU SUNCAR SEALS CO.,LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
D9691500 Seals Repair Kit for Hydraulic Breaker HK200 BHI Hydroram
Description: D9691500 Hydraulic Breaker Service Kit
| Product name | D9691500 Seals Repair Kit for Hydraulic Breaker HK200 BHI Hydroram |
| Brand name | SUNCAR |
| OEM number | D9691500 |
| Fits model | HK200 |
| MOQ | Accept trial order |
| Function | Dust proof, Shaft seal,high and low temperature resistance |
| Material | PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Temp. | FKM(-20~200°C) , Silicone (-70~220°C) |
| Temp. | EPDM(-50~150°C), PU(-40~90°C) |
| Temp. | NBR(-40~120°C), FFKM(-20~320°C) |
| Supply alility | 550 sets per week |
| Condition | 100 % new,brandnew |
| Feature | High efficiency, Long life |
| Transport mode | Air, Sea, Express ( FedEx , UPS,DHL,TNT etc.) |
| CertifiC-A-Tion | ISO9001 |
| Market | North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Middle East, Africa, Oceania, Worldwide |
| Working temperature | -30°~+110°C -25°~+220°C (Depend on material of O-ring) |
| Working speed | ≤4m/s |
| Size specifiC-A-Tion | Standard size |
| AppliC-A-Tion | Breaker;Construction machinery repair store;Resell store |
| Stock | In rich stock |
| Make up | Packing rod;dust seal;O-ring,back-up ring;piston ring;wear ring |
| Style | Hydraulic seal kit;Breaker seal kit |
Our Services:
1. We offer a warranty of 6 months from the date of shipment.
2. Competitive price and short lead time.
3. The more quantity you order, the more favorable price we can
offer.
4. We have a professional team to provide you with professional
services.
5. When quoting, parts will be given weight, specifiC-A-Tion,
price, etc.
6. Accept trial order and sample order.
7. All parts can be checked by part number and ordered by part
number.
8. Wooden CNHs, cartons, etc can be provided to protect the safe
packing of the goods.
About Us:
Our company has been a manufacturer and supplier in China's machinery industry for many years. We provide high-quality, hard-wearing, highly
cost effective cylinder seal kit. Our product use the high quality material production, conforms to the standard. It is committed to providing
customers with excellent service and competitive price.
HK200 Spare Seal Kit Parts List:
| NO | Part No. | Part name | Qty |
| 0 | D9691500 | Spare Seal Kit | 1 kit |
| 1 | 22402160 | O-ring | 2 |
| 2 | 22402070 | O-ring | 6 |
| 3 | 22402040 | O-ring | 3 |
| 4 | 22405630 | Back up ring | 1 |
| 5 | 22409290 | Back up ring | 3 |
| 6 | 22402230 | O-ring | 3 |
| 7 | 22401670 | O-ring | 1 |
| 8 | 22401600 | O-ring | 2 |
| 9 | 22402110 | O-ring | 1 |
| 10 | 22200070 | Gas seal | 1 |
| 11 | 22300060 | Step Seal | 2 |
| 12 | 22000230 | Buffer seal | 1 |
| 13 | 22003940 | U Packing Seal | 1 |
| 14 | 220002690 | Dust Seal | 1 |
| 15 | 22402060 | O-ring | 2 |
| 16 | 22501660 | U-seal | 4 |
| 17 | 22402350 | O-ring | 1 |
| 18 | 22401420 | O-ring | 1 |
| 19 | 22401440 | O-ring | 1 |
| 20 | 22401930 | O-ring | 1 |
| 21 | 22500260 | Back up ring | 1 |
| 22 | 22401430 | O-ring | 1 |
| 23 | 22402020 | O-ring | 2 |
HK200 Tool Kit Parts List:
| NO | Part No. | Part name | Qty | Remarks |
| 0 | Tool Kit | 1 | HK200 | |
| 1 | 16502990 | Tool Box | 1 | No.1 |
| 2 | 16500260 | Combi Spanner | 1 | 14mm |
| 3 | 16502510 | Single Spanner | 1 | 32mm |
| 4 | 16502100 | Double Spanner | 1 | 27*30mm |
| 5 | 16502530 | Single Spanner | 1 | 41mm |
| 6 | 16501140 | L-Wrench | 1 | 5mm |
| 7 | 16501170 | L-Wrench | 1 | 10mm |
| 16501190 | L-Wrench | 1 | 14mm | |
| 16501200 | L-Wrench | 1 | 17mm | |
| 16501210 | L-Wrench | 1 | 19mm | |
| 16500710 | Handle Ring Wrench | 1 | 46mm | |
| 16500760 | Handle Ring Wrench | 1 | 70mm | |
| 16500770 | Handle Ring Wrench | 1 | 75mm | |
| 16503090 | Handle Retainer Pin | 1 | M12 |
Shipping:
1. Professional loader teams
2. Professional goods shipping forwarder
3. PP bag inside, carton box outside(General export packing or
customized packing as your request.
Our Advantages:
1. Customized design: If your qty up to 100 pcs,we can customize for any size or material,packaging you need.If you have any requirement ,pls
contact us,we will try our best to demand your requirement.
2. High quality: Products are enjoying great reputation for its
diversifiC-A-Tion,Innovation,and Superior Quality
3. The most favorable price: We are manufacturer that can give you
the most reasonable price.
4. Material safety: It is very safe for appliC-A-Tion and can be
used with confidence in expected appliC-A-Tions.
5. More than 10 years experiend in construction machinery seal and seal kit line,so we can provide you professional service.
6. Large stock,welcome to place order.
7. Good timeliness , we have been delivering on time within the specified time.
8. Releasing new items periodically and customizing products to OEM quality
9. Excellent services and durable uses of products
10. Strict quality control
11. Fast delivery
|
