| Categories | Polyethylene Pipe Fittings |
|---|---|
| Brand Name: | LUTONG |
| Model Number: | DN63-DN1200 |
| Certification: | BSI |
| Place of Origin: | CHINA |
| MOQ: | NEGOTIATION |
| Price: | NEGOTIATION |
| Supply Ability: | 10000 PER MONTH |
| Delivery Time: | NEGOTIATION |
| Packaging Details: | CARTON |
| Material: | PE80 or PE100 or MDPE or HDPE |
| Standard: | EN |
| Application: | Gas pipe, water pipe |
| Original: | Cangzhou city, China |
| Shape: | Square |
| Working Pressure: | PN4-16 |
| Name: | Polyethylene Pipe Fittings |
| Payment Terms: | NEGOTIATION |
Quick Details
PE100 SDR11 Elbow 90 degree applied for gas pipeline pressure reach 0.7Mpa, and water-supply pipeline pressure reach 1.6Mpa;
PE80 SDR11 Elbow 90 degree applied for gas pipeline pressure reach 0.5Mpa, and water-supply pipeline pressure reach 1.25Mpa;
PE 100 SDR17.6 and SDR 17 Elbow 90 degree applied for gas pipeline pressure reach 0.4Mpa, and water-supply pipeline pressure reach l.OMpa;
PE80 SDR17.6 and SDR 17 Elbow 90 degree applied for gas pipeline pressure reach 0.3Mpa, and water-supply pipeline pressure reach 0.8Mpa;
The welding voltage 40V, the bar code on the coupler gives the best welding parameters.
Features&Application
Recycled and Environment-friendly
Applied to agricultural irrigation, construction site, drainage and pump etc.
We provide OEM/ODM service
Sample order is free
Factory price
| d mm | e(SDR11) mm | e(SDR17) mm | e(SDR17.6) mm | L mm | L1 mm |
| 110 | 10.0 | 6.6 | 6.3 | 154 | 84 |
| 160 | 14.6 | 9.5 | 9.1 | 206 | 99 |
|
