4x2 Drive Standard 8000Kg Water Tanker Fire Fighting Vehicles with Lenghten Cab

Categories Water Tanker Fire Truck
Brand Name: CIMC Jindun
Model Number: SG120
Certification: ISO9001,CCCF, TUV, SGS, SCONCAP, PC
Place of Origin: Shanghai,china
MOQ: 1 unit
Price: Factory price,Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 units/year
Delivery Time: 120 days
Packaging Details: Exporting standard package or customized packing
Chassis brand: SINOTRUK HOWO or MAN (optional )
LxWxH: 10180×2500×3650mm
Weight: 33320kg
Power: 276kw
Wheel base: 4600+1350mm
Emission standard: China IV
Loading weight: 30090kg
Modified Crew: 2+4
Drive type: 6×4
Water: 8000L
Product name: Water tanker fire truck
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

4x2 Drive Standard 8000Kg Water Tanker Fire Fighting Vehicles with Lenghten Cab

4x2 Drive Standard 8000Kg Water Tanker Fire Fighting Vehicles with Lenghten Cab


SG80/H water tank fire truck is modified from 2nd class chassis which produced by China National Heavy Duty Truck Group Co., Ltd. The equipment compartment, water tanker room and pump room are structured separately.The layout of the whole vehicle is reasonable.


Chassis

ManufacturerSinotruk HOWO
ModelZZ5347V4647D5
Drive type6x4
CabFlattop four door length
Wheelbase4600+1350mm
Max. speed85km/h
Min. turning diameter<22m
Approach angle16°
Departure angle12°
Engine typePressure combustion, in-line six-cylinder, water cooling, inter-cooling, direct injection diesel engine
ModelD10.38-40
Max. power276kw
Max. torque1560N•m
Emission standardChina IV/ Euro IV
ClutchMonolithic, dry
Gearbox modelManual 10forward gear

Fire monitor

ModelWeisite PL64
PositionRear roof
Flow64L/s
Pressure1.0MPa
Rangewater≥70m
Rotation angle

Level ≥270°

Max. elevation angle ≥+45°

Max. depression angle ≥-7°


Liquid tank

CapacityWater: 8000kg
Material304 high quality corrosion resistant plate
StructureTotal side girder
Pressure1.0MPa
Device

2 ingate

1 overflow device

1 liquid level sensor

1 DN50 drain outlet with valve

4 filling pipe end

Conform to rule GA39.4-92




FAQ:

1. Q:Are you a factory or a trade company?

A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.


2. Q:Where is your factory located?

A:We are located in Shanghai Province,China.


3. Q:What's your payment method?

A: T/T and L/C are preferred.


4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.


5. Q: How is the packing?

A:All the packing comply with exporting standard.


6. Q: What's the delivery time?

A: 1) 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

2) ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

3) European brand chassis 9 months upon receipt of advance deposit.


Any other questions, please do not hesitate to contact with us.
