LSZH Fiber Optic Cable , Indoor Single Mode Armored Fiber Cable

Categories	Fiber Optic Cable
Model Number:	Indoor Armored Fiber Optic Cable
Certification:	CE Rohs SGS ISO
Place of Origin:	China
MOQ:	MOQ : 1000meter
Price:	Price : Negotiable
Payment Terms:	Payment Terms:T/T, L/C,paypal,Western Union
Supply Ability:	Supply Ability : 6,000,000 KM per year
Delivery Time:	Delivery Time :3 to 5 days for sample orders, 7 to 15days for bulk order
Packaging Details:	Packaging Details : according to the quantity of the order
Tight buffer type:	0.6 / 0.9mm PVC / LSZH tight buffer
Operating temperature:	-40 to +70
Product name:	Indoor Armored Cable
Jacket color:	Blue / Grey/ Yellow / Orange

Contact Now

Add to Cart

Company Info.

Shenzhen Hong An Jia Technology Co.,Ltd.

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

LSZH Fiber Optic Cable , Indoor Single Mode Armored Fiber Cable

Indoor Armored Fiber Optic Cable Indoor Fiber Optic Cable PVC Or LSZH Inner Sheath

Description:

The structure of the cable is put 900μm or 600μm tight buffer fibers with aramid yarn, then covered with a

layer of PVC or LSZH inner sheath, then wrapped a layer of flat stainless steel wires and add a layer of woven stainless steel wire, finally complete with PVC or LSZH sheath.

Specification:


		G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20℃)	850nm			≤3.0dB/km	≤3.0dB/km
	1300nm			≤1.0dB/km	≤1.0dB/km
	1310nm	≤0.36dB/km	≤0.36dB/km
	1550nm	≤0.22dB/km	≤0.23dB/km
Bandwidth (Class A)	850			≥500MHZ·km	≥200MHZ·km
Bandwidth (Class A)	1300			≥1000MHZ·km	≥600MHZ·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength		≤1260nm	≤1480nm
