ASTM A240 S30116 Stainless Steel Strip Coil Flat Cold Rolled

UNS S30116 Type 301Si ASTM A240 Stainless Steel Precision Stainless Steel Strip 2BA Hard For Springs​ overview

Type 301Si is an austenitic stainless steel capable of attaining very high strengths while maintaining ductility through cold working. It is not hardenable by heat treatment. Type 301Si is non magnetic in the annealed condition and becomes increasingly magnetic when cold worked. 301Si has an increased silicon content over standard 301 and is typically used for "super" high strength applications. The extra silicon allows for even better ductility at high tensile strengths than standard 301. Both are produced to ASTM A666.

UNS S30116 301Si ASTM A240 Precision Stainless Steel Strip Specification and Dimension Ranges

301 Stainless Steel Specifications:

ASTM A240 for annealed condition
ASTM A666 for tempered material

Hot Rolled Strip Available Size

Width: 16.0~609.6 mm
Thickness: 2.5~10.0 mm
Available Steel Grade:

Cold Rolled Strip Available Size

Width: 4.0~609.6 mm
Thickness: 0.1~3.0 mm

Surface Finish:

2B, 2D, BA, No.3, No.4, No.5, SB, HL, etc

Condition :

ANNEALED CONDITION

Ultimate Tensile Strength: 95 KSI min (655 MPA min) Yield Strength (0.2% Offset): 38 KSI min (260 MPA min) Elongation: 40%min Hardness: B95 max

TEMPERED 1/16 HARD

Ultimate Tensile Strength: 95 KSI min (655 MPA min) Yield Strength (0.2% Offset): 45 KSI min (310 MPA min) Elongation: 40% min

Tempered 1/8 Hard Ultimate Tensile Strength: 100 KSI min (690 MPA min) Yield Strength (0.2% Offset): 55 KSI min (380 MPA min) Elongation: 45% min

TEMPERED 1/4 HARD

Ultimate Tensile Strength: 125 KSI min (860 MPA min) Yield Strength (0.2% Offset): 75 KSI min (515 MPA min) Elongation: 25% min

TEMPERED 1/2 HARD

Ultimate Tensile Strength: 150 KSI min (1035 MPA min) Yield Strength (0.2% Offset): 110 KSI min (760 MPA min) Elongation: 15% < 0.15" 18% > 0.15"

TEMPERED 3/4 HARD

Ultimate Tensile Strength: 175 KSI min (1205 MPA min) Yield Strength (0.2% Offset): 135 KSI min (930 MPA min) Elongation: 10% < 0.15" 12% > 0.15"

TEMPERED FULL HARD

Ultimate Tensile Strength: 185 KSI min (1275 MPA min) Yield Strength (0.2% Offset): 140 KSI min (965 MPA min) Elongation: 8% < 0.15" 9% > 0.15"

Available Steel Grade:

Stainless steel : Type 201, 202, 205, 301, 302, 302B, 303, 303Se, 304, 304L, 302HQ, 304N, 305, 308, 309, 309S, 310, 310S, 314, 316, 316L, 316F, 316N, 317, 317L, 317LMN, 321, 330, 347, 348, 384, 405, 409, 429, 430, 430F, 430FSe, 434, 436, 442, 446, 403, 410, 414, 416, 416Se, 420, 420F, 422, 431, 440A, 440B, 440C, 630 , 13-8 PH ,15-5 PH , 17-7 PH ,17-4 ph , 904L , A286 ,VG-10 , SAE 316 , SAE 316L , SAE 440 , SAE 420

Duplex stainless steel : 2205 , 2304 , 2507

Nickel alloy :

Titanium and titanium alloys

UNS S30116 Type 301Si ASTM A240 Stainless Steel Precision Stainless Steel Strip 2BA Hard For Springs Application

• Springs
• Fasteners
• Washers
• Zippers
• Clips
• Clamps
• Computer Parts
• Contacts
• Stampings of a wide variety of parts
• Pins

CHEMISTRY TYPICAL

Carbon: 0.15 max Manganese: 2.00 max Silicon: 1.3 max Chromium: 16.00-18.00 Nickel: 6.00-8.00 Molybdenum: 0.75 max Phosphorus: 0.040 max Sulfur: 0.030 max Copper: 0.75 max Nitrogen: 0.10 max Iron: Balance

PHYSICAL PROPERTIES

Density: 0.285 lbs/in3 7 .88 g/cm3

Electrical Resistivity: microhm-in (microhm-cm): 68 °F (20 °C): 27.4 (69.5)

Specific Heat: BTU/lb/° F (kJ/kg•K): 32 -212 ° F (0 -100 °C): 0.12 (0.50) Thermal Conductivity: BTU/hr/ft2/ft/° F (W/m•K) At 212 ° F (100 °C)-9.4 (16.2), At 932 ° F (500 °C)-12.4 (21.4) Mean Coefficient of Thermal Expansion: in/in/° F (µm/m•K) 32-212 ° F (0-100 °C)-9.4 x 10·6 (16.9) 32-600 ° F (0-315 °C)-9.9 x 10·6 (17.8) 32 -1000 ° F (0 -538 °C)-10.2 x 10·6 (18.4) 32 -1200 ° F (0 -649 °C)-10.4 x 10·6 (18.7)

Modulus of Elasticity: ksi (MPa) 28.0 x 103 (193 x 103) in tension 11 .2 x 103 (78 x 103) in torsion

Magnetic Permeability: H = 200 Oersteds: Annealed < 1.02 Melting Range: 2250-2590 ° F (1399-1421 °C)

FORMS

Coil -Strip, Foil, Ribbon Wire -Profile, Round, Flat, Square

MECHANICAL PROPERTIES AT ROOM TEMPERATURE

PROPERTIES: TYPICAL

Ultimate Tensile Strength: 75 KSI min (515 MPA min) Yield Strength: (0.2% offset): 30 KSI min (205 MPA min) Elongation: 40% Min Hardness: B92 or Equiv. Max

TEMPERED CONDITION

301Si is available in the tempered condition. Consult Ulbrich Technical Services for properties.

FINISHES - STRIP & FOIL

#1 - Hot rolled annealed and descaled. It is available in strip, foil and ribbon. It is used for applications where a smooth decorative finish is not required.

#2D - Dull finish produced by cold rolling, annealing and descaling. Used for deep drawn parts and those parts that need to retain lubricants in the forming process.

# 2B - Smooth finish produced by cold rolling, annealing and descaling. A light cold rolling pass is added after anneal with polished rolls giving it a brighter finish than 2D.

#BA- Bright annealed cold rolled and bright annealed

#CBA- Course bright annealed cold rolled matte finish and bright anneal

#2 - Cold Rolled

#2BA- Smooth finish produced by cold rolling and bright annealing. A light pass using highly polished rolls produces a glossy finish. A 2BA finish may be used for lightly formed applications where a glossy finish is desired in the formed part. Polished - Various grit finish for specific polish finished requirements.

301 stainless steel strip Cold rolled BA Full hard Slit edge For washers Products display and Package Details

301 stainless steel strip Cold rolled Equivalent
