| Categories | Metal Grinding Discs |
|---|---|
| Brand Name: | Grassland |
| Model Number: | 100X3.0X16 |
| Certification: | MPA EN 12413 and ISO 9001,ISO14001 |
| Place of Origin: | China |
| MOQ: | 10000 PCS |
| Price: | US$0.16-0.22 |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 300 thousand PCS PER day |
| Delivery Time: | 30-60 Days |
| Packaging Details: | shrink wrap-inner box-carton-enhanced pallet |
| abrasive: | aluminium oxide |
| color: | black |
| Hardness: | R |
| Max working speed: | 80 M/S |
| Grit size: | 24#,30#,46#,60# |
| Iterm NO.: | FAC1003016 |
| Application: | Ferrous metal and steel cutting |
| Bonding agent: | resin bonded |
| arbor size: | 5/8 in |
| Disc type: | depressed center type |
Grinding Metal Disc 100 X 3 X 16mm
• Bore 16mm
• Disc Diameter 100mm
• Bond Type Resinoid Reinforced (BF)
- Outer diameter 100mm.
- Inner bore diameter 22.23mm.
- Thickness 3.2mm.
- Maximum circumferential speed: 80 m/s (depending on rpm and disc diameter)
- Max 15300 rpm.
• Manufactured to assure operator safety and optimum performance. For use with all portable angle grinders.
• For use on steel, Metal and non-ferrous materials
• Iron, sulphur and chlorine free.
• Abrasive Material Aluminium Oxide
- Provides fast and smooth cutting.
- Appropriate for hand-held angle grinders.
Grassland High Quality Alumina reinforced bonded resin Cutting Discs are made with scientifically formulated and apportioned ingredients. Each disc is designed with quick cutting, low heat production, safety and longevity in mind. Our High Quality Alumina Cutting Discs get the job done effectively and efficiently.
| Cutting wheel information: | |||
| Product Name | 100mm metal grinding discs | Abrasive | Aluminum oxide |
| Hardness | R Grade | Net Standard | Reinforced fiberglass |
| Max working speed | 80 m/s | OEM Service | Acceptable |
| R.P.M | 15300 | Package | Kraft Carton and Pallet |
| Grit size | 24#,30#,46#,60# | HS Code | 68042210 |
Certificate | MPA EN12413,ISO9001 | Loading Port | Tianjin or else |
| Description of goods | Item No | Specification | Unit | PCS/CTN | N.W./G.W.(KGS) | CARTON SIZE(CM) |
| Depressed Cutting disc for metal 80m/s | DAC1002516 | T42-100X2.5X16MM | PC | 200 | 8/9 | 22*22*20.2 |
| DAC1152522 | T42-115X2.5X22.2MM | PC | 200 | 12/13 | 24.5*24.5*20.2 | |
| DAC1252522 | T42-125X2.5X22.2MM | PC | 200 | 14/15 | 26.5*26.5*20.2 | |
| DAC1502522 | T42-150X2.5X22.2MM | PC | 150 | 15/16 | 34*26*17 | |
| DAC1802522 | T42-180X2.5X22.2MM | PC | 150 | 19.5/20.5 | 40*20*26 | |
| DAC2302522 | T42-230X2.5X22.2MM | PC | 50 | 11.5/12.5 | 24*24*20.7 | |
| DAC2502522 | T42-250X2.5X22.2MM | PC | 50 | 11.5/12.5 | 25*25*19 | |
| Depressed Cutting disc for metal 80m/s | DAC1003216 | T42-100X3.2X16MM | PC | 400 | 21.5/20.5 | 22X22X19.7 |
| DAC1153222 | T42-115X3.2X22.2MM | PC | 200 | 14/15 | 24.5*24.5*22.2 | |
| DAC1253222 | T42-125X3.2X22.2MM | PC | 200 | 16/17 | 26.5*26.5*22.2 | |
| DAC1503222 | T42-150X3.2X22.2MM | PC | 200 | 25/26 | 32*32*22.2 | |
| DAC1803222 | T42-180X3.2X22.2MM | PC | 100 | 18/19 | 37.5*19*23.7 | |
| DAC2303222 | T42-230X3.2X22.2MM | PC | 50 | 14/15 | 24*24*23.7 | |
| DAC2503222 | T42-250X3.2X22.2MM | PC | 50 | 17.5/16.5 | 25*25*21 |





|
