| Categories | Foam Fire Truck |
|---|---|
| Brand Name: | CIMC |
| Model Number: | JDX5420GXFPM220/H |
| Certification: | ISO9001,CCC |
| Place of Origin: | shanghai China |
| MOQ: | 1 unit |
| Price: | negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time: | 90days |
| Dimension: | 11775×2500×3700 |
| Gross weight: | 41980kg |
| Seat (inc. driver): | 6 |
| Max. power: | 309kw |
| Drive type: | 4x2 |
| Max. speed: | 95Km/h |
| Capacity: | water 16000L |
| Foam: | 6000L |
| Company Info. |
| Shanghai Jindun special vehicle Equipment Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
309kw Max Power Water And Foam Fire Trucks High Balance Precision Transmission Shaft
Vehicle
| Dimension (L×W×H) | 11775×2500×3700mm |
| Gross weight | 41980kg |
| Complete vehicle shipping mass | 18000kg |
| Seat (inc. driver) | 6 |
| Max. power | 309kw |
Chassis
| Manufacturer | Sinotruk HOWO |
| Model | ZZ5437V4667D5 |
| Drive type | 8x4 |
| Cab | Flattop metal forward type |
| Wheelbase | 1800+4600+1350mm |
| Max. speed | 95km/h |
| Min. turning diameter | ＜30m |
| Approach angle | 16° |
| Departure angle | 13° |
| Engine type | Inline six-cylinder, water inter-cooling, direct injection diesel engine |
| Model | D12.42—40 |
| Max. power | 309kw |
| Max. torque | 1820N•m |
| Emission standard | China IV |
| Clutch | Pull, dry |
| Gearbox model | Manual, 10 forward gear |
Equipment tank
| Material | Q235A high quality steel combine with porous steel |
| Structure | Split type welding structure |
| Equipment compartment door | The light quality aluminum alloy, with shutter doors, lightweight and reliable. |
| Internal structure | the inner frame for the introduction of aluminum lap technology, can maximize space utilization and variability within the equipment, users can request allocation of various sliding bracket, carriage, rotating frame, and high strength plastic storage box and so on, the structure from the space utilization, aesthetic appearance, ease of handling equipment have reached the international advanced level. |
Pedal plate
Location: At the bottom of roller shutter door
Material: Steel frame covered by aluminum alloy checkered plate
Structure: adopt the gas springs plus shutter fasten, safe and
Reliable, each petal plate bearing ≥150Kg
|
