| Categories | Wireline Pressure Control Equipment |
|---|---|
| Brand Name: | Ruixin |
| Model Number: | 12 inch 14inch 16inch |
| Certification: | API |
| Place of Origin: | China Baoji |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 1 set 3 weels |
| Delivery Time: | 3-4 weeks |
| Packaging Details: | Wooden Box |
| Name: | Wireline Hay Pulley Wellhead Wireline Pressure Control |
| Material: | Cast aluminum |
| Sheave Size: | 12inch~16inch |
| Operation: | Wireline operation and slickline operation |
| Use: | Well intervention |
| Wireline PCE: | Wireline Hay Pulley |
| Company Info. |
| Ruixin Energy Equipment |
| Verified Supplier |
| View Contact Details |
| Product List |
Wireline Pressure Control Wireline Hay Pulley
Ⅰ.Introduction
The Hay Pulley is used to control and manipulate the direction of the wireline or braided cable from a horizontalpositon to a vertical position en route to the stuffing box from the wireline unit. This tool is generally positioned at the wellhead on the lubricator to reduce side pull force and to avoid lateral loading of the lubricator during heavy jarring operations.
The Hay Pulley is used to control and manipulate the direction of the wireline from a horizontal positon to a vertical position en route to the stuffing box from the wireline unit. This tool is generally positioned
at the wellhead on the lubricator to reduce side pull force and to avoid lateral loading of the lubricator during heavy jarring operations.
The hay pulley is used to pull the wire or cable ( braided cable ) from the top of the lubricator to the drum surface of the wire or cable, so that the tension point of the wire or cable (braided cable ) is moved from the top to the production tree, thus reducing the tension load of the wire or cable (braided cable ) side and preventing the damage of the lubricator from being bent. The hay pulley
can also be lifted to change the direction of the load on the wire or cable (braided cable ).
| Size | Wire sie | Safe working load |
| 12" | TBA. | |
| 14" | 7/32" 5/16" | |
| 16" | 7/32" 5/16" 15/32" | 20KN |
|
