5 - 300mm Dia Bearing Steel Tube , 1 - 30mm Thickness Hydraulic Seamless Pipe

Categories Bearing Steel Tube
Brand Name: New-Era
Model Number: SAE52100
Certification: TS16949/ISO9001
Place of Origin: China
MOQ: 500kg
Price: Negotiation
Payment Terms: L/C, T/T
Supply Ability: 2000tons per month
Delivery Time: 20-30days
Packaging Details: anti-rusty oil,bundles packing with plastic bags wrapped
Materials: GCr.15 100Cr6
Standard: SAE52100
Size: Dia 5-300mm thickness 1-30mm
plated: Nickel or white or black
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

5 - 300mm Dia Bearing Steel Tube , 1 - 30mm Thickness Hydraulic Seamless Pipe

Seamless Bearing Steel Tube for Bearing Ring SAE52100 GCr15 100Cr6


Standard: JIS-SUJ2 GB-GCr15 ASTM A295 DIN-100Cr6
Outer Diameter: 5-329mm
Thickness: 1mm-30mm
Length: 5-12m


The Main Technical Parameter of the finished product
GradeChinaISOAmericaGermanyJapanEngland
GCrl51SAE52100100Cr6SUJ-2S135

Chemical CompositionCSiMnCrpSCuNiMO[O]
0.95
~
1.05
0.15
~
0.35
0.25
~
0.45
1.40
~
1.65
max
0.025

max
0.025

max
0.02

max
0.02

max
0.10

max
10PPM
Surface
Hardness
HB179 ~ 207
Decarbonization
Deepth
Outer SurfaceInner Surface
max0.25mmmax0.25mm
Outside Diameterφ5m~φ329mm
Wall
Thickness
1mm~30mm
Dimensions
Tolerance
Outside DiameterThicknessLengthCamberEllipticity
+0.4mm
-0.00mm
+0.30mm
-0.30mm
3~7m≤1mm/m≤0.08
