| Categories | Heavy Duty Dump Truck |
|---|---|
| Brand Name: | Sinotruk Duty Dump |
| Model Number: | Howo7 Duty Dump |
| Certification: | iso ccc |
| Place of Origin: | China |
| MOQ: | 1unit |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200units/week |
| Delivery Time: | 30days |
| Packaging Details: | nude |
| Price: | $13000-$35000 |
| material: | Q235 |
| color: | black |
| product name: | Duty Dump |
| brand: | Sinotruk howo7 |
| emission stander: | Euro2 |
| tire: | 12.00R20 |
| Company Info. |
| Jinan Heavy Truck Import & Export Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
6x4 10 tires HOWO 336 hp new condition diesel fuel type dump truck with Q345 Steel heavy tipper
Dump Truck Specifications:
| SINOTRUK HOWO 336HP 6x4 dump truck/tipper truck | |||
| Truck Model | ZZ3257N3447A | ||
| Cargo Body Size (LxWxH) | 5200x2300x1200 mm | ||
| Lifting Type | Ventral Lifting | ||
| Overall dimensions (LxWxH) | 7835*2496*3170 mm | ||
| Approach angle/Departure angle(°) | 19/27 | ||
| front/rear suspension (mm) | 1500/1560 | ||
| Axle base (mm) | 3425+1350 | ||
| Max speed(km/h) | 75 | ||
| Vehicle Curb weight(kg) | 12380 | ||
| Gross mass (kg) | 25000 | ||
| Engine | Model | SINOTRUK WD615.69, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and intercooling | |
| Power, max(kw/rpm) | 336 HP | ||
| Emission | Euro2 | ||
| Transmission/Gear box | Model | HW19710, 10 speeds forward ,2 reverse | |
| Brake system | Service brake | Dual circuit compressed air brake | |
| Parking brake | spring energy, compressed air operating on rear wheels | ||
| Auxiliary brake | Engine exhaust brake | ||
| Steering system | Model | ZF8118,hydraulic steering with power assistance | |
| Front axle | HF 9,drum | ||
| Driving axle | HC16,double reduction | ||
| Tire | 12.00R20,radial tyres; optiong:12.00-20 | ||
| Clutch | φ430 diaphragm spring clutch,hydraulic control air power assisted | ||
| Cab | HW70, with A/C VOLVO technology ,comfortable cab. 4-point support floating suspension and shock absorbers, up/down and front/back adjustable steering wheel, VDO instrument and control module,safety belt , air horn,outer sun visor. | ||
| Electric system | Battery | 2x12V/165Ah | |
| Alternator | 28V-1500 KW | ||
| Starter | 7.5 Kw/24 V | ||
| Color | red,white,yellow. Optional as per customer’s requests. | ||
