Stainless Steel Plastic Washing Recycling Machine With 4-5 Rollers 156 KW

Stainless Steel Plastic Washing Recycling Machine With 4-5 Rollers 156 KW

Plastic Washing Recycling Machine Description:

Plastic bottle rinsing tank is used in waste plastic bottle scrap recycle, to wash the waste bottle after crushing, the tank width is 1700mm, it has 4-5 rollers over the floating tank.

The Protective cover is over the floating washer.

One motor under the screw tank 1.5KW.

Main Technical of bottle rinsing tank :

Plastic Washing Recycling Machine Features:

• The blade on crusher, it will be changed every 24hours, of course, it will according how dirty is your pet bottles. The knife sharpener machine needed.
• The part which with water are all made of 304 stainless steel, so the equipment life is very long.
• This China Hot Selling Waste PET Bottle Washing plant can easily wash and recycle waste PET bottle flakes. Equipment at the end of the washing line so that the completely dry flakes can be collected and packed directly after being washed.

The whole production line can be designed on the basis of how dirty the flakes are, and make sure of the quality of the final products.

Plastic Washing Recycling Machine Parameter

Plastic Washing Recycling Machine Application:

As recycling line for waste bottles, the machine is suitable for recycling all kinds of
PET bottles, such as drink bottles, yogurt bottles, laundry detergent bottles and etc.

Plastic Washing Recycling Machine Advantages:

-Final products has good quality. When process PET bottle, final products humidity below 1%, impurities100ppm,PVC label content 100ppm . The whole line capacity between 300kg/h-2000kg/hour

-Parts which contact material use SUS304 stainless steel, thickness more than 3mm, ensure long service lift time

-World famous brand components applied on the production line- e.g. SKF bearing, Siemens contactor, Omron temperature, Siemens PLC controller, etc.

-The whole production line with CE certification, ISO9001 certification;

Plastic Washing Recycling Machine working principle:

recycled PET plastic bottles, firstly to remove the labels for label remover machine, and then go though selecting table to select different color bottles( for example, green bottles,bule bottles or other PC ,HDPE bottles etc. then go to crusher to crush , when the material come out ,then go to floating washer , to separate PET bottles with PP labels ,cups. After separating, it will go to high degree temperature hot washer boil to hot washing, then go to cold floating washer again (to remove the detergent from hot washer, then dewatering ,package.

For the different capacity ,high level bottle flakes, we can design the new plan as your requirement.

STPLAS GROUP is a creative company, focusing on the technology R&D of plastic recycling, and providing the equipment and solutions for plastic washing, recycling and granulating.
STPLAS GROUP's plastic recycling technology mainly applied in the field of waste plastic regrinding, washing and regranuling. Thanks to the R&D ability and well-understanding industries's experience, STPLAS GROUP can provide the customized plastics recycling solutions to customers.

STPLAS MACHINERY has our own R & D team , We will provide the highest quality product “QUALITY IS OUR CULTURE.” STPLAS will design as your local factory requirement, each line is special.

Warmly welcome to visit us. We trust you will choose us!

We customize totally production lines for each customer! You just need to tell us your demands.

We produce PET washing recycling machine line, PP/PE recycling washing line. Each machine line includes crushing-washing-drying process.

We also produce plastic granulating machine line. If you want to make clean plastic flakes into small particles, you can also contact us.

We also produce plastic shredder, film squeezing machine, plastic crusher, agglomerator, mixing machine, pipe fitting injection machine, plastic compounding machine etc.

Of course, if part of your machine line needs to be replaced, we can also help you replace it according to your existing production line.

OUR ADVANTAGE:

1. Specialized R&D team involved in plastics recycling industries more than 15 years;
2. Ability to provide the customized plastic recycling solutions;
3. Complete sales system covering the pre-sale, sales and after sales;
4. Professional engineers will perform debugging and technical guidance.
