Min. Speed of steel cable 4.5m/min Road Wrecker Truck 1 Year Warranty 4x2 drive

Categories Road Wrecker Truck
Brand Name: YD
Model Number: KFM5062TQZ10D
Certification: ISO9001:2008
Place of Origin: CHINA
MOQ: 1 SET
Price: USD
Payment Terms: T/T, L/C
Supply Ability: 50 SETS PER MONTH
Delivery Time: 30 working days
Packaging Details: standard package in container
Numbers of winch: 1
Dimension: 5437×1940×2410
Axle base: 3360mm
Drive: 4×2
Length of steel cable: 25m
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Min. Speed of steel cable 4.5m/min Road Wrecker Truck 1 Year Warranty 4x2 drive

Min. Speed of steel cable 4.5m/min Road Wrecker Truck 1 Year Warranty 4x2 drive


1. Main Parameters

ItemsUnitValue
Boom StructureRated towing weightkg5900
Max. Lifting weightkg1930
Lifting weight of full extending boomkg1410
Effective length of boommm1678
Extension traveling of boommm470
Folding angle of boom°90
Under lift StructureRated hanging weightkg1500
The height from hook to the groundmm4070
Extension traveling of hanging boommm1400
Numbers of winchpiece1
Max. Pulling power of winchkg4000
Diameter of steel cablemm10
Length of steel cablem25
Min. Speed of steel cablem/min4.5
Rotation angle°42

Vehicle

Parameters

External dimensionmm5437×1940×2410
Chassis modelNKR77LLPACJAY
Axle basemm3360
Drive4×2
The whole weight of empty loadkg3885
Load of front axle of empty loadkg1885
Load of rear axle of empty loadkg2000
The whole weight of full loadkg5945
Load of front axle of full loadkg2035
Load of rear axle of full loadkg3910
Wheel base (front/rear axle)mm1504/1425
Front suspensionmm1015
Rear suspensionmm900
Approach angleº20
Departure angleº18
Min. Turning diameterm≤15.2
Max. Speedkm/h100
Grade ability%30
Min. Ground clearancemm190
Engine model-4KH1-TC
Rated powerkw/r/min96/3400
Max. Torquen·m/r/min280/1700
Fuel typeDiesel
Standard of emissionEN III
Tire size

7.50-15,7.00-16,

7.50R15,7.00R16

Persons2

2,Standard Equipments

1. ISUZU NKR77LLPACJAY

2. Main boom structure assembly

3. Vice boom assembly

4. Hanging hook assembly

5. Control structure assembly

6. Winch assembly (include winch clutch, impaction device)

7. Steel body assembly

8. Tool box assembly

9. Light stands assembly

10. Alarm device

11. Hydraulic system

12. Hydraulic system over voltage protection device

13. Electric system

14. PTO Warner

15. Combination lamps

16. Steel wire rope (including hook) (25m/pcs)

17. Standard spare tire

18. L wheel lift

19. Bind belt

20. Vulnerable parts attachment
