| Categories | Wall Hung Gas Boiler |
|---|---|
| Brand Name: | Dongyuan |
| Model Number: | L1PB18-HI |
| Certification: | ISO14001,ISO9001,OHSAS18001 |
| Place of Origin: | China,Shunde |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union, D/A |
| Supply Ability: | 10000pcs per month |
| Delivery Time: | 30days after receiving the deposit |
| Packaging Details: | Each product in plastic bag which comes with the product instructions and foam packaging, then carton packaging outside with another thicker plastic bag.Each product in plastic bag which comes with the product instructions and foam packaging, then carton p |
| Gas type: | NG or LPG |
| Structure: | Water Tube |
| Burning Style: | Radiator |
| Function: | Hot Water Boiler |
| Usage: | Home |
| Company Info. |
| Foshan Dongyuan Thermal Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| Gas Central heating Environmental Protection For Heating And Domestic Hot Water Gas Boiler | ||||
| Technical data | ||||
| Electric Power(W) | 110 | 110 | 110 | 110 |
| Gas Type | NG/LPG | |||
| Rated Gas Pressure(Pa) | 2000/2800 | |||
| Power Supply | 20-50HZ | |||
| Model Number | L1PB18 | LIPB20 | L1PB24 | L1PB28 |
| Rated Gas Input(kw) | 18 | 20 | 24 | 28 |
| Rated Gas Output(kw) | 15.9 | 17.6 | 21.1 | 24.7 |
| Heating Area(㎡) | 70-140 | 80-160 | 100-200 | 160-260 |
| Lift Of pump(m) | 5 | 5 | 5 | 6 |
| Expansion Tank Capacity(L) | 6 | 6 | 6 | 8 |
| Application Water Pressure(Mpa) | 0.1-0.3 | |||
| Efficiency Under Rated Heat Input(%) | Above 88% | |||
| Temp.Range Of Heating Water(℃) | Radiator:30-80 Floor Heating:30-60 | |||
| Preset Pressure Of Expansion Vessel(Mpa) | 0.1 | |||
| Water Circulation Type | Airtight Forced Circulation | |||
| Applicative Water Pressure(mpa) | 0.03-0.8 | |||
| △T=25℃ Hot Water Supply(kg/min) | 9 | 10 | 12 | 14 |
| △T=30℃ Hot Water Supply(kg/min) | 7.5 | 8.3 | 10 | 11.7 |
| The Minimum Closed Flow(L/min) | 1.6 | |||
| Connections(mm) | For Gas&Heating Water Pipes:G3/4 For DHW Pipes:G1/2 | |||
| The Minimum Starting Flow (L/min) | 2 | |||
| Temp.Range Of DHW Supply(℃) | 30-60 | |||
| Air Input/Exhaust Duct(mm) | φ60/φ100 | |||
| Sparated Input/Exhaust Duct(optional) | φ80/φ100 | |||
| The length Of Flue Dust(m) | 1 | |||
| Noise On Working(DB) | ＜42 | |||
| Exhaust Type | Forced Exhaust | |||
| Ignition Type | Integrated Automatic Ignition | |||
| Temperature Control | Gas Proportional Adjustment | |||
|
