Emulsifier Cosmetic Manufacturing Equipment , Automatic Ointment Manufacturing Plant

Emulsifier Cosmetic Manufacturing Equipment , Automatic Ointment Manufacturing Plant

Cosmetic Manufacturing Equipment DESCRIPTION

Lift type machine is designed specially by our company for cosmetic and pharmaceutical industries to produce and deal small batches of different varieties of products. The most feature is that the main tank lid can lift automatically, thoroughly clean the tank, the tilting discharging method can be fully assured the material completely out.

Mixing use triple blender, which is the design that have positive and negative turn of matching a high speed emulsifier head and a slow stirring mixer.

Cosmetic Manufacturing Equipment STANDARD CONFIGURATION

1. Min boiler, water tank, oil tank

2. Vacuum pump and synchronous solenoid valve

3. Emulsifier and material filter

4. Oil pressure lifting system and blending system

5. Stainless steel operation platform

Cosmetic Manufacturing Equipment OPTIONAL CONFIGURATION

1. Variable-frequency converter and electric control box

2. Touch screen

3. Built-in PLC

Vacuum emulsifying main machine:
· Slow mixer 10-40rpm with PTFE scraper
· Homogenizer 1150-3500rpm (rotor and stator can adjust space)
· Heating by steam or electricity
· Pressure: chamber-0.09Mpa to 0.1Mpa, jacket 0.3Mpa for steam (standard type)
· Upper cover lifting by hydraulic
· Safety limit switch for safety operation
· Upper cover connection: Liquid feed inlet with stainless steel pipe filter, solid material inlet, vacuum inlet, compressed air inlet, breaking vacuum inlet, sight glass, CIP cleaning head, discharging port, dustproof respirator.

Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine

Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump

Cosmetic Manufacturing Equipment Parameters

NOTE: Due to make toothpaste, the motor power have different type, so pls contact us, we will choose a suitable machine for you. we have engineer work for toothpaste factory more than 10 year also have machinery design experience.

As a professional manufacturer and exporter, DingYi I/E Industrail Co., Ltd Engages in the research, design, manufacture and sale of various machines.

Our factory specializes in making kinds of pharmaceutical, cosmetic and food machinery, for instance, Vacuum emulsifying mixer, Suppository vacuum emulsifier, Toothpaste making machine, Tube filling and sealing machine, Bottom homogenizing cream mixer, Soft gel preparation system, Dry type granulator, Color mixing machine, CIP cleaning system, Stainless steel mixing and storage vessel, Gel storage tank, Online high-shear emulsifier, Sanitary rotor pump and centrifugal pump, Colloid mill, water and powder mixer, Belt conveyor.


Our company always contributes to produce products satisfying customers.

We are very pleased to cooperate with you to create our bright future.
