Hotel Restaurant Sliding Acoustic Partition Wall / Hanging Soundproof Room Dividers Partitions

Hanging Dividers Partition System Hotel Restaurant Sound Proof Sliding Acoustic Partition Walls

Acoustic partition walls technical information

Acoustic partition walls features

1. Top hung with no floor track required.
2. High acoustic ratings up to 50dB available.
3. Retractable acoustic seals at top and bottom of each acoustic partition walls panel operated either by a quick release handle.
4. Single or twin point suspension for central or offset stacking options.
5. Variable track arrangements.
6. Junction panels enable corner, three or four way abutments.
7. Panel finishes include Melamine Laminate, Veneer, Vinyl, Magnetic Dry Wipe Whiteboard or Painted, etc.
8. Optional inset pass doors, fully glazed panels and vision panels.
9. Closure panel fitted with face operated telescopic "nose".


Acoustic partition walls FAQ

1. Do your acoustic partition walls systems come in standard sizes?

No, all of our acoustic partition walls systems are customized depending on your exact requirements.

2. Do you provide acoustic partition wall design services?

In our technical team, we have experienced CAD technicians with many years experience of acoustic partition walls layout design.

3. What level of acoustics do I need?

65 type - Max height 3.5 m,soundproof 38-43 dB.
85 type - Max height 5.5 m,soundproof 43-53 dB.
100 type - Max height 7 m, soundproof 43-58 dB.
125 type - Max height 17 m, soundproof 48-58 dB.

4. Are you the manufacturer of acoustic partition walls?

We are one of the very few manufacturers of acoustic partition walls in China, which offers many advantages in a dynamic and competitive market. Recent investments in new manufacturing equipments have enabled us to provide market leading advantages such as:
We do not have to rely on a potentially unreliable supply chain.
We can offer the most competitive prices on the market.
We can be your operable wall supplier Philippines, and any other country.
All operable walls are customized to suit for your project.

5. What surface treatments are available?

Melamine, Laminates(MDF), Wood Vaneer, Paint and Various Wallpaper. However, it is also possible to accommodate a more professional surface treatment such as sound absorption panel and perforated board.

6. How do I support acoustic partition walls in a building?

The acoustic partition wall is composed of a plurality of individual panels supported by an overhead track system. Due to the lack of floor support or rail, the overhead track supports the full loading of the acoustic partition wall.
This is usually done by using pre-fabricated brackets which are secured to the structure at a pre-calculated interval according to the weight of the acoustic partition walls. The most common materials commonly used in overhead structures are steel or iron. Although we can advise on the loading density of the acoustic partition walls and the weight of brackets used, the structural engineer of the scheme has a responsibility to determine whether the fixed structure is sufficient.

Guangdong Bunge Building Material Industrial Co., Ltd is a professional company in manufacturing Movable Partitions, Folding Doors, Sliding Doors, Office Furniture. We also artistically designs and carefully do research and development (R&D).

Ebunge company has adopted the advanced partition technology of USA, Germany and Denmark. We have a professional staff with more than 10 years of experience in design, production, and installation. Also, have a good after-sale system and team.

Our products (Movable Partitions and Acoustic Panels) are widely used in hotel banquet halls, meeting rooms, exhibition halls, conference rooms, international convention centers, KTVs, upscale restaurants, office buildings, schools, hospitals auditoriums, stadiums,s and so on.

Nowadays, the modern trend in buildings needs more flexibility and convenience, acoustic and soundproof to use the space of their rooms. Most of building designers like to prepare an open-plan space, with soundproof effects, and easy to operate. The solution to the designer's need is the Movable Partitions and Acoustic Panels..

The movable partition walls can be customized with various surface finishes, such as melamine, MDF, Plywood, fabric and PU leather. Top hanging system with only ceiling but no floor tracks so it can be pushed and pulled everywhere easily according to the direction of tracks. The most popular panel thickness is 85mm and its height can be up to 6 meters. Both wooden and glass operable walls are available in our factory which can meet different requirements of our customers.

Movable Wall Manufacturer
◆Individual panels can be stored away for maximum space usage.
◆Operable top and bottom seals for effortless operation.
◆Aluminum frame construction for enhanced acoustics.
◆The system offers various levels of sound reduction
◆Unique track and carrier system ensuring quiet and easy operation.
◆Numerous panel stacking options for complete flexibility.
◆Top hung and no floor track.
◆Extensive range of surface finishes can be available.

Movable partition wall production

We Offer:

◆ A full professional design service

◆ Survey and installation guide

◆ Using top quality materials and components

◆ A fully experienced work team

◆ Maintenance contracts to ensure your valuable asset remains in full work order.

Movable partition wall loading container

Movable partition wall loading container
