Multi - Pull Cargo Container Movers Container Semi Trailer Light Self - Weight

​​Multi-Pull Cargo Container Trailer Container Semi Trailer Light Self-Weight

Description:

The cargo box semi trailer is suitable for the transportation of household appliances, textile goods, coal, sand and other building materials and goods.

Advantages:

• strong bearing capacity

The cargo box semi trailer has strong bearing capacity, high safety factor, reasonable design, ruggedness and durability, and advanced manufacturing technology.

• Van structure

The box body is made of high strength cold-bonded corrugated steel plate, which has large loading space without skeleton structure, reasonable distribution in the box body and X-shaped stretching brace. It has the characteristics of multi-pull, heavy load and light self-weight.

• Different options

The side wall height and side or back door numbers and opening ways have several options for your better usage.

Specifications:

DIMENSIONS
Tare Weight	8900KGS	Payload	45000KGS
Overall Length	13000mm	Overall Width	3950mm
Technical Data
Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm; Bottom Flange 16mm,width 140mm.
Axle	3 axles
	Brand Name: BPW, L1, or FUWA-Optional upon requirement
Suspension	Mechanical suspension or Air Suspension upon requirement
Spring	8-piece leaf spring
King Pin	2” Bolt-in King Pin
Landing Gear	Two-speed, manual operating, heavy duty landing gear
Wheel Rim	8.5-20, 8.25-22.5, 9.0-22.5-Optional upon tire requirement
Tyre	11.00-20, 12.00-20, 11.00R20, 12.00R20, 11R22.5, 12R22.5-Optional
Spare Tyre	One set of spare tire including a carrier
Braking System	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories	One standard tool box
