Home > Lamp Poles >

40Ft Power Transmission Poles Hot Dip Galvanised Steel Pole Q345 Octagonal Shape

Categories Power Transmission Poles
Brand Name: JSHG
Model Number: HG-SP-110KV
Certification: ISO/CNAS/IAF/CA
Place of Origin: China
MOQ: One 40 HQ Container
Price: negotiation
Payment Terms: L/C, T/T or Western Union
Supply Ability: 3,000 Metric Tons per Month
Delivery Time: 2 weeks per container after PO / drawing / prepayment confirmed
Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Application: 69KV Electrical Power Transmission Line
Shape: Octagonal
Material: Q345
Design Load: 500kg
Appearance Treatment: Hot-dip galvanized
Welding: According to AWS D 1.1, CO2 welding or submerged arc auto methods
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

40Ft Power Transmission Poles Hot Dip Galvanised Steel Pole Q345 Octagonal Shape

Philippines Market 40Ft Electrical Power Transmission Poles Hot Dip Galvanized Q345


Product Detial:


National Electrification Administration (Philippines)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT


Height(ft)Thickness(mm)Butt Diameter(mm)Top Diameter(mm)Design Load(kg)Yield Stress(MPA)Zinc Coating(microns)
252.515212030034586
303.022612750034586
353.024812750034586
403.031712750034586

40FT Details


TypeDirect Burial Type
Shape of poleOctagonal (8 sides)
Diameter127mm / 317mm
MaterialQ345 equivalent to Grade 50
Thickness3.0mm
Design Load500KGS
WeldingWelding complies with CSA and AWS, AWS D1.1 standard.
The welders have got corresponding certificate after testing and inspection.
StandardNEA
GalvanizingHot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123.

Product Description:


Products

  • Philippines Market 40Ft Electrical Power Transmission Poles Hot Dip Galvanized Q345

Application

  • Electrical Power transmission and distribution line

Standrad

  • Philippines NEA Standard

Shape

  • Conical, Octagonal

Material

  • Applied to the material of general-purpose steel GB/T1591-2008, Q345 used in China.

    Q345 equipment to ASTM GR50. Min Yield Stress 345 Mpa.


Wall thickness

  • 2.5-3.0 mm

Type

  • Direct Buried

Welding

  • Welding of substation structure complies with AWS D1.1 standard. CO2 welding or submerged arc auto methods

  • No fissure, scar, overlap, layer or other defects. Internal and external welding makes structure more beautiful in shape

Life Period

  • More than 25 years, it is according to installing environment

Advantages

  • Less Land Occupation
  • Low Overall Cost
  • Easy Installation and Maintenance
  • Anti-corrosion
  • ODM & OEM are available
  • Provide Professional Design by Our Experienced R&D Engineers

  • Capable to Handle Volume Orders

Material Test:


1. All of our materials are purchased from famous mill factory to assure the quality with mill certificate issued by the mill factory before unloading the material in our factory;


2. Before putting into production, all the materials must pass the chemical and physical analysis to make sure that they have met the requested strength and components.



Packaging&Shipping:


Our poles as normal are covered by Mat or straw bale at the top and bottom and woods between the poles can avoid the damage of the galvanization on the surface of steel poles, anyway also we can follow clients required.



Our Service


  • Reply within 24 Working Hours
  • Factory Direct Sale
  • More than 15 Years Design & Manufacture Experience
  • Capable to Handle Volume Orders
  • High-Quality and Low-Price Product
  • Provide Professional Design by Our Experienced R&D Engineers
  • Rich Exporting Experience
  • ODM, OEM Acceptable
  • Technical Support by E-mail
  • Calling service

Contact Us:


Jiangsu Hongguang Steel Pole Co., Ltd.

Address: Wanshi Industrial Zone, Yixing City, Jiangsu Pro., P.R.China, 214212

Telphone: +86 510 878 441 56

Fax: +86 510 878 435 28

Trade manager ID: cnhgsteelpole

Skype: tangjia870124


Please feel free to contact us!
