Triangle Type Integrated Solar Led Street Light 12000 Lumen 8 Meters With Smart Control System

Categories Integrated Led Solar Street Light
Brand Name: NOMO
Model Number: Solar Pole Light (H8)
Certification: IP65, CE, ROSH, ISO9000
Place of Origin: CHINA
MOQ: Negotiation
Price: Negotiation
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: IN STOCK
Delivery Time: IN STOCK
Packaging Details: NEUTRAL PACKING
Dimension of product: 8 meters
Modules: 4
Lumen output: 12000LM (minimum)
LED Chip: 5050
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Triangle Type Integrated Solar Led Street Light 12000 Lumen 8 Meters With Smart Control System

HELIOS, NOMO’s newest series, which have a smart remote management system (for option) which uses latest wireless communication technology, that enables each light to be governed securely from any given location, ensuring reliable operation even under the harshest conditions.


FEATURES:


1. Easy to install:

It doesn’t require an electrical grid, digging or experience with electricity. All you need to do is to put the light in a sunny spot, let it charge and enjoy.


2. Require no maintenance:

You won’t have to worry about maintenance with using Hyperion Integrated LED Solar Street Light. All they need is to make sure the solar panel on each light working at its best.


3. Integrated design:

LED solar fixtures can be used as area lights, street lights, wall lights, driveway lights, parking lot lights, security night lights, patio lights, flood lights or yard lights.


4. MPPT controller, the tracking efficiency reaches 99.9%, charging conversion efficiency 98.5%.


PARAMETER:


MODEL NO.H8 with HP-5000 lamp
PARAMETERS
Solar Panel
PV Module400W
Life Time25 Years
(the power attenuation of each year is around 1%)
Light Parameter
LampHP-5000
LED Chip5050
LED Luminous12000LM
LED Module4 Moduels
Viewing Angle70°*140°
Color Temperature3000K-6500K, typical (5500K-6000K)
Color Rendering Index﹥70
Life Time50000 Hours
Battery
Battery TapeLiFePO4 Battery
Battery Capacity1500WH
Battery Life Time(5-8 Years)
Controller
MPPT Charge ControllerIncluding wireless communication module
Timing Mode1Hr 50% ,4Hrs 100%,3Hrs 50%,4Hrs 25%.(Settable)
Circuit ProtectionOvercharge, Discharge, Short circuit, Open load,
Lightning protection and other functions
Life Time(5-8 Years)
Charging Time (STC)6-8 Hrs (At STC)
Certificates
CertificateCE, ROSH, IP65, ISO9000, IEC
Environment Requirement
Working Temperature-20℃~70℃
Storage Temperature0℃~45℃
Protection GradeIP65
Installation8 Meters

INSTALLATION NOTE:


1.All in one solar street light power can be stored at maximum time of 6 months, after being fully charged.


2.Regular inspection needed, due to longer transportation and storage periods, otherwise battery life will be shortened.


3.In the northern hemisphere, the solar panel facing towards south, gets the best direction for absorbing ideal energy. If this installation done on opposite or either side hemisphere, one must make sure to avoid, any house, trees, or any kinds of shadows covering any part of the panel, which could cause reduction in efficiency and working performance.


4.Always keep the solar panel clean from (dust, tree leaves, greasy dirt, bird poop ) by cleaning with water.
