Acoustic partition walls details

Our soundproof acoustic partition walls utilises up to date materials.It can attain much higher levels of sound attenuation than was previously achievable with a folding partition. The soundproof acoustic partition wall is extremely easy to use and incorporates important features ,such as integral passing door and a flush appearance when closed.

It is available as a ceiling track to hang system with our without floor location pins, or as a floor mounted system supported on an ultra low profile floor track that can be installed flush with the floor covering.

The floor mounted system utilises a ceiling guide track that can accommodate an adjustment tolerance of 22.5 mm. both systems are avialble as centre or end tracking.

The soundproof acoustic partition walls system has a unique closing device, which helps the operator achieve a flush wall in one easy movement before closing the end pass door panel. This is particularly convenient when using a ceiling hung partition without floor track.

Soundproof acoustic partition wall offers unique custom made Acoustic Movable Wall Partitions which facilitates in managing.Your space to its maximum capacity. Our movable partition wall system constitutes of panels.

Suspended individually from the rail fixed to the top of the roof. The soundproof acoustic partition wall has retractable top and bottom seals which interlocks each panel to its position. If required, hinged pass doors shall be provided through the soundproof acoustic partition walls where access is required.

Acoustic partition walls features

Soundproof acoustic partition wall has top hung with no floor track.

Scissor-jack operating mechanism.

Available with virtually any surface finish.

Ideal for conference centres, hotels, offices & schools.

Angled, glazed, corner or junction panels for maximum flexibility.

Single or double point suspension for versatile stacking options.

Panels with hinged pass door, single or double leaf inset pass door panels for access through.

Technical information

Aluminium accessoreis system:

Soundproof acoustic partiiton wall seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23 mm.

For single or paired panels up to 250 kg. One 4-wheeled carrier is provided per panel, each wheel is consists of molded polymer tires on hardened steel ball bearings.Resilient mounted body for quite operation and load distribution.special for center stacking option. Usual dimension from the ceiling to the structure is 200mm.

For panel up to 225 kg. Two carriers are provided per panel. Each carrier has two horizontal counter-rotating wheels that roll (not slide) in the track. Each wheel has precision ground bearings, encased with POM for quiet operation. Carriers easily negotiate square or angled corners without switches. Usual dimension from the ceiling to the structure is 200 mm.

Guangdong Bunge Building Material Industrial Co., Ltd is a professional company in manufacturing Movable Partitions, Folding Doors, Sliding Doors, Office Furniture. We also artistically designs and carefully do research and development (R&D).

Ebunge company has adopted the advanced partition technology of USA, Germany and Denmark. We have a professional staff with more than 10 years of experience in design, production, and installation. Also, have a good after-sale system and team.

Our products (Movable Partitions and Acoustic Panels) are widely used in hotel banquet halls, meeting rooms, exhibition halls, conference rooms, international convention centers, KTVs, upscale restaurants, office buildings, schools, hospitals auditoriums, stadiums,s and so on.

Nowadays, the modern trend in buildings needs more flexibility and convenience, acoustic and soundproof to use the space of their rooms. Most of building designers like to prepare an open-plan space, with soundproof effects, and easy to operate. The solution to the designer's need is the Movable Partitions and Acoustic Panels..

The movable partition walls can be customized with various surface finishes, such as melamine, MDF, Plywood, fabric and PU leather. Top hanging system with only ceiling but no floor tracks so it can be pushed and pulled everywhere easily according to the direction of tracks. The most popular panel thickness is 85mm and its height can be up to 6 meters. Both wooden and glass operable walls are available in our factory which can meet different requirements of our customers.

Movable Wall Manufacturer
◆Individual panels can be stored away for maximum space usage.
◆Operable top and bottom seals for effortless operation.
◆Aluminum frame construction for enhanced acoustics.
◆The system offers various levels of sound reduction
◆Unique track and carrier system ensuring quiet and easy operation.
◆Numerous panel stacking options for complete flexibility.
◆Top hung and no floor track.
◆Extensive range of surface finishes can be available.

Movable partition wall production

We Offer:

◆ A full professional design service

◆ Survey and installation guide

◆ Using top quality materials and components

◆ A fully experienced work team

◆ Maintenance contracts to ensure your valuable asset remains in full work order.
