| Categories | Electric Steam Generator Boiler |
|---|---|
| Brand Name: | GAOYI |
| Certification: | ISO9001 |
| Place of Origin: | CHINA |
| MOQ: | 1set |
| Price: | negotiable |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 30 Units Per Month |
| Delivery Time: | 20 working days |
| Packaging Details: | Sea-Worthy Packing or Air-Worthy Packing |
| Fuel: | electric |
| Style: | Horizontal |
| Usage: | Industrial |
| Condition: | New |
| After-sales service provided: | Overseas service center available |
| Operation: | full automatic |
| Model | Nominal capacity (t/h) | Rated pressure(Mpa) | Rated steam temperature(℃) | Thermal efficiency (%) | Dimensions (m) | Weight(kg) |
| LDR0.2-0.4 | 0.2 | 0.4 | 151 | 99 | 1.0×2.5 | 750 |
| LDR0.3-0.4 | 0.3 | 0.4 | 151 | 99 | 1.1×2.6 | 920 |
| LDR0.4-0.4 | 0.4 | 0.4 | 151 | 99 | 1.2×3.0 | 1100 |
| LDR0.5-0.4 / 0.7 | 0.5 | 0.4/0.7 | 151/170 | 99 | 1.2×3.2 | 1350 |
| LDR0.7-0.4 / 0.7 | 0.7 | 0.4/0.7 | 151/170 | 99 | 1.3×3.5 | 1800 |
| WDR1-0.7 | 1 | 0.7 | 170 | 99 | 3.0×1.4×1.65 | 2100 |
| WDR1.5-0.7 | 1.5 | 0.7 | 170 | 99 | 3.5×1.6×1.75 | 2600 |
| WDR2-0.7 | 2 | 0.7 | 170 | 99 | 4.0×1.7×1.95 | 3100 |
Note :1. The parameters are for reference only. If there is any
change, please follow the actual drawing. 2. The following are the parts of boiler products, please ask for
specific details. | ||||||
|
