| Categories | Steel Fitting |
|---|---|
| Brand Name: | YUHONG |
| Model Number: | ASTM A234 WPB , ASTM A860, ASTM A420 |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Place of Origin: | CHINA |
| MOQ: | 1PC |
| Payment Terms: | L/C, T/T |
| Delivery Time: | 7DAYS |
| Packaging Details: | PALLET OR PLYWOOD CASE |
| MATERIAL: | WPB,WPC,WPHY42,WPHY46,WPHY52,WPHY56,WPHY60,WPHY65,WPHY70,WPHY80 |
| STANDARD: | ASTM A234 , ASTM A860, ASTM A420 |
| OD: | 1/4" TO 100" |
| WT: | SCH10S To XXS |
| PACKAGE: | PALLET OR PLYWOOD CASE |
| SURFACE: | Black Painting Or Other Color Coating |
| Company Info. |
| Yuhong Group Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Carbon Steel Butt Weld Fitting , ASTM A234 WPB ,CAP , BW B16.9 , SCH STD , SCH40, SCH80 Black Painting
In general, carbon steel pipe fittings and flanges are widely used for applications which do not require materials with higer resistance to corrosion such as stainless steel and nickel alloys. Carbon steel products corrode and get rusted easily if exposed to water.
Products information:
Size : 1/8"NB TO 100"NB
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80,
SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated /Forged
Form : Eccentric Reducer, Concentric Reducer
Materials
Stainless Steel Reducer - SS Reducer
ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347,
904L
Carbon Steel Reducer - CS Reducer
ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 &
WPHY 70.
Low Temperature Carbon Steel Reducer - LTCS Reducer
ASTM A420 WPL3 / A420WPL6
Alloy Steel Reducer - AS Reducer
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP
91
Duplex Steel Reducer
ASTM A 815 UNS NO S 31803 , S 32205.
Nickel Alloy Reducer
Standard
Value Added Services
Test Certificate
Mill Test Certificate as per EN 10204 / 3.1B
| Nominal Pipe Size | Outside Diameter | Inside Diameter | Wall Thickness | Length | Pipe Schedule | Weight Pounds |
| 1/2 | 0.84 | 0.622 | 0.109 | 1 | 40 | 0.08 |
| 3/4 | 1.05 | 0.824 | 0.113 | 1.25 | 40 | 0.14 |
| 1 | 1.32 | 1.049 | 0.133 | 1.5 | 40 | 0.21 |
| 1 1/4 | 1.66 | 1.38 | 0.14 | 1.5 | 40 | 0.33 |
| 1 1/2 | 1.9 | 1.61 | 0.145 | 1.5 | 40 | 0.54 |
| 2 | 2.38 | 2.067 | 0.154 | 1.5 | 40 | 0.8 |
| 2 1/2 | 2.88 | 2.469 | 0.203 | 1.5 | 40 | 1 |
| 3 | 3.5 | 3.068 | 0.216 | 2 | 40 | 1.7 |
| 3 1/2 | 4 | 3.548 | 0.226 | 2.5 | 40 | 2.3 |
| 4 | 4.5 | 4.026 | 0.237 | 2.5 | 40 | 2.8 |
| 5 | 5.56 | 5.047 | 0.258 | 3 | 40 | 4.6 |
| 6 | 6.62 | 6.065 | 0.28 | 3.5 | 40 | 6.9 |
| 8 | 8.62 | 7.981 | 0.322 | 4 | 40 | 11.8 |
| 10 | 10.75 | 10.02 | 0.365 | 5 | 40 | 20.8 |
| 12 | 12.75 | 12 | 0.375 | 6 | * | 30.3 |
| 14 | 14 | 13.25 | 0.375 | 6.5 | 30 | 36.5 |
| 16 | 16 | 15.25 | 0.375 | 7 | 30 | 43.5 |
| 18 | 18 | 17.25 | 0.375 | 8 | * | 57 |
| 20 | 20 | 19.25 | 0.375 | 9 | 20 | 75.7 |
| 24 | 24 | 23.25 | 0.375 | 10.5 | 20 | 101 |
| 30 | 30 | 29.24 | 0.38 | 10.5 | * | 137 |
| 36 | 36 | 35.24 | 0.38 | 10.5 | * | 175 |
| 42 | 42 | 41.24 | 0.38 | 12 | * | 229 |
| 48 | 48 | 47.24 | 0.38 | 13.5 | * | 350 |
| Nominal Pipe Size | Outside Diameter | Inside Diameter | Wall Thickness | Length | Pipe Schedule | Weight Pounds |
| 1/2 | 0.84 | 0.546 | 0.147 | 1 | 80 | 0.1 |
| 3/4 | 1.05 | 0.742 | 0.154 | 1.25 | 80 | 0.16 |
| 1 | 1.315 | 0.957 | 0.179 | 1.5 | 80 | 0.28 |
| 1 1/4 | 1.66 | 1.278 | 0.191 | 1.5 | 80 | 0.48 |
| 1 1/2 | 1.9 | 1.5 | 0.2 | 1.5 | 80 | 0.67 |
| 2 | 2.375 | 1.939 | 0.218 | 1.5 | 80 | 0.92 |
| 2 1/2 | 2.875 | 2.323 | 0.276 | 1.5 | 80 | 1.3 |
| 3 | 3.5 | 2.9 | 0.3 | 2 | 80 | 2.1 |
| 3 1/2 | 4 | 3.364 | 0.318 | 2.5 | 80 | 3 |
| 4 | 4.5 | 3.826 | 0.337 | 2.5 | 80 | 3.5 |
| 5 | 5.563 | 4.813 | 0.375 | 3 | 80 | 5.8 |
| 6 | 6.625 | 5.761 | 0.432 | 3.5 | 80 | 9.3 |
| 8 | 8.625 | 7.625 | 0.5 | 4 | 80 | 16 |
| 10 | 10.75 | 9.75 | 0.5 | 5 | 60 | 26 |
| 12 | 12.75 | 11.75 | 0.5 | 6 | * | 38 |
| 14 | 14 | 13 | 0.5 | 6.5 | * | 47 |
| 16 | 16 | 15 | 0.5 | 7 | 40 | 57 |
| 18 | 18 | 17 | 0.5 | 8 | * | 78 |
| 20 | 20 | 19 | 0.5 | 9 | 30 | 100 |
| 24 | 24 | 23 | 0.5 | 10.5 | * | 145 |
| 30 | 30 | 29 | 0.5 | 10.5 | 20 | 634 |
| 36 | 36 | 35 | 0.5 | 10.5 | 20 | 913 |
| 42 | 42 | 41 | 0.5 | 12 | * | 1,300 |
| 48 | 48 | 47 | 0.5 | 13.5 | * | 1,675 |
|
