SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet

Categories Alloy Steel Plate
Brand Name: MITTEL
Model Number: ASTM A387
Certification: ISO MTC SGS
Place of Origin: China
MOQ: 500KGS
Price: 1.2 USD/KG
Payment Terms: L/C, T/T
Supply Ability: 5000Ton
Delivery Time: 7 Days
Packaging Details: Wodden Pallet
Application: Boiler Plate
Technique: Hot Rolled
Type: Steel Plate
Width: 600mm-1250mm,2000-2300mm
Special use: Alloy structual steel
Grade: alloy steel plate
Thickness: 2-100mm
Material: Alloy Structual Steel
Price term: CIF CFR FOB EX-WORK
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet

SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet


ASTM A387 GRADE 11 Class 2

As a pressure vessel grade steel for use in elevated temperature service, is used in a variety of industries and is highly effective, particularly in the oil, gas and petrochemical industry, where liquids and gases are often stored at higher temperatures.

The higher levels of chromium also provide excellent corrosion and oxidation resistance, which is a must in sour gas applications. Please refer to our technical specifications below for ASTM A387 Grade 11 Class 2...

Equivalents

BSENASTM/ASMEDIN
621 B–––A387-11-2–––

Specifications for ASTM A387 Grade 11 Alloy Steel Plates

Chromium & Molybdenum content (according to the ASME specification)
DesignationNominal Chromium
Content (%)
Nominal Molybdenum
Content (%)
A387 Grade 111.25%0.50%

Tensile Requirements for ASTM A387 Grade 11 Alloy Steel Plates Class 1 Plates

Designation:Requirement:Grade 11
A387 Grade 11Tensile strength, ksi [MPa]75 to 100 [515 to 690]
Yield strength, min, ksi [MPa]/(0.2% offset)43 [310]
Elongation in 8 in. [200mm], min %18
Elongation in 2 in. [50mm], min, %22
Reduction of area, min %–––

Chemical Requirements for ASTM A387 Grade 11 Alloy Steel Plates

ElementChemical Composition (%)
A387 Grade 11
Carbon:Heat Analysis:0.05 - 0.17
Product Analysis:0.04 - 0.17
Manganese:Heat Analysis:0.40 - 0.65
Product Analysis:0.35 - 0.73
Phosphorus:Heat Analysis:0.035
Product Analysis:0.035
Sulphur (max):Heat Analysis:0.035
Product Analysis:0.035
Silicon:Heat Analysis:0.50 - 0.80
Product Analysis:0.44 - 0.86
Chromium:Heat Analysis:1.00 - 1.50
Product Analysis:0.94 - 1.56
Molybdenum:Heat Analysis:0.45 - 0.65
Product Analysis:0.45 - 0.70
