| Categories | Milk Bottle Blow Molding Machine |
|---|---|
| Brand Name: | DAWSON |
| Model Number: | ABLB80 |
| Certification: | CE |
| Place of Origin: | CHINE |
| MOQ: | 1 piece |
| Price: | USD 20000-50000 piece |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 25 pieces per month |
| Delivery Time: | 45-65 days |
| Packaging Details: | wooden |
| Hollow part volume:: | 10~30L |
| Applicable Industries: | Manufacturing Plant |
| Clamping System: | Toggle Type Clamping System |
| Suitable Material: | HDPE,PP,PVC,PS,PETG,LDPE |
| Air Comsumption(m³/mi: | 1 m³/min |
| Warranty: | 1 year |
| Air Pressure(MPa): | 0.8 MPa |
| Company Info. |
| Dawson Machinery & Mould Group Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
| Unit | Item | Specification | |
| Machine type | ABLB82PC | Accumulator head | |
| Extruding unit | max. container capacity | 25 | L |
| screw diameter | 82 special for PC | mm | |
| screw L/D ratio | 38: 1 | L/D | |
| screw speed | 10-80 | rev. /min | |
| plasticizing capacity | 90 | kg/h | |
| number of heating zone | 7 | zone | |
| extruder heating power | 16.7 | kw | |
| Die head | max accumulator capacity | 1.85 | L |
| max injection speed | 1 | kg/sec | |
| max head tooling diameter | 130 | mm | |
| die head heating zone | 4 | zone | |
| die head heating power | 12.3 | kw | |
| Clamping unit | platen valid size(w× h) | 800× 800 | mm |
| platen daylight | 250-800 | mm | |
| clamping force | 220 | kn | |
| Bottom blowing unit (optional) | expansion stroke | 140-350 | mm |
| blow pin auto-lifting stroke | 100 | mm | |
| blow pin manual-lifting stroke | 200 | mm | |
| Robot arm (optional) | moving stroke | 1000 | mm |
| Machine frame | lifting stroke | 350 | mm |
| lifting speed | 30 | mm/min | |
| Hydraulic system | main-pump rated pressure | 12 | mpa |
| main-pump rated volume | 180 | L/min | |
| hydraulic driving power | 45 | kw | |
| parison control hydraulic servo system | MOOG | ||
| Rated volume | 23 | L/min | |
| hydraulic pump power | 4 | kw | |
| Pneumatic system | max. pressure | 8 | kg/cm2 |
| operating pressure | 0.6 | mpa | |
| air consumption | 0.4 | m 3 /min | |
| Water source | water supply pressure | 0.3 | mpa |
| Electricity | Voltage | AC380± 10% | V |
| Frequency | 50 | HZ | |
| Phase | 3 phase 4 wire | ||
| Installation capacity | total rated power | 78 | kw |
| average consumption | 42 | kw/h | |
| total weight | 11.8 | ton | |
| dimension(L× W× H) | 6000× 2200× 4500 | mm | |
|
