Mindray BeneHeart R12 ElectrocardiograPHiliph ECG Machine Hospital Medical Equipment

Hospital Medical Equipment Mindray BeneHeart R12 ElectrocardiograPHiliphhilip ECG Machine

► Brief Introduction

BeneHeart R12 electrocardiograPHiliphhilips are intended to acquire, analyze, display, store, and record electrocardiograPHiliphhilipic information for adult and children of any age from birth upwards for clinical diagnosis and study.

The equipment can be used to:

• Acquire, analyze, displays, and record 12-lead ECG information.
• Provide ECG algorithm to automatically analyze the acquired ECG waveforms; output measurements and diagnosis.
• Support auto measurement, manual measurement, and rhythm measurement.
• Print ECG reports through either an internal thermal recorder or an external printer.
• Store, preview, and review ECG reports.
• Connect LAN or Wi-Fi to send ECG data.
• Support entering patient information through the keyboard or a barcode reader.
• Present messages in case of lead off, interference, low battery, or other abnormity.

► Main Unit

The electrocardiograPHiliphhilip consists of the following assemblies:

• Top cover assembly: consists of major button board, display, touchpad board (only for the equipment not configuring a touchscreen), and keyboard kit.
• Middle frame assembly : consists of main board (including the mother board and the daught board), thermal module, USB adapting board, speaker, power management board, ECG board, battery interface board, and AC-DC module.
• Lower cover assembly : is the paper tray assembly.

►Front View

1. Thermal recorder: prints reports.

2. Hard keys.

3. Indicators.

4. Display screen: presents waveforms and text.

5. Soft keys: for the equipment configured with a touchscreen. Press the soft keys to select the options. Soft key labels: for the equipment not configured with a touchscreen.

6. Soft keys: only for equipment not configured with a touchscreen. The soft keys illuminate when the equipment is powered on. Press the soft keys to select the options that appear on the right side of the screen. For the equipment configured with a touchscreen, there are no keys in this area.

7. USB connector: connects USB devices, such as a USB drive, external printer, or barcode reader.

8. Patient cable connector: connects the patient cable for ECG acquisition.

9. Keyboard.

►Technical Specifications

►Turning On the Equipment

Once the equipment has been installed and checked, you can get ready for measurement and recording:

1. Connect the equipment with AC mains. If you run the equipment on battery power, ensure that the battery is sufficiently charged.

2. Press the Power switch.
