FAG Cylindrical Roller Bearing RNU205E.TVP , RNU205-E-TVP

FAG Cylindrical Roller Bearing RNU205E.TVP , RNU205-E-TVP

FAG Cylindrical Roller Bearing RNU205E.TVP , RNU205-E-TVP
FAG Cylindrical Roller Bearing RNU205E.TVP , RNU205-E-TVP
Categories Cylindrical Roller Bearing
Model Number: RNU205E.TVP , RNU205-E-TVP
MOQ: 1PCS
Price: FOB
Packaging Details: Carton Box
Delivery Time: within one day
Payment Terms: T/T In advance
Supply Ability: 5000PCS
Brand Name: FAG
Place of Origin: Germany
Contact Now
Company Info.
YiWu Triumph Bearing Co.,Limited
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

FAG Cylindrical Roller Bearing RNU205E.TVP , RNU205-E-TVP

N type:
The inner ring has two integral flanges and the outer ring is without flanges. Axial displacement of the shaft with respect to the housing can be accommodated in both directions within the bearing itself. The bearings are therefore used as non-locating bearings.
NU type:
The outer ring of bearings of the NU design has two integral flanges and the inner ring is without flanges. Axial displacement of the shaft with respect to the housing can be accommodated in both directions within the bearing itself.
NJ type:
The outer ring has two integral flanges and the inner ring one integral flange. The bearings are therefore suitable for the axial location of a shaft in one direction.
NF type:
The outer ring has one integral flange and the inner ring two integral flanges.
NUP type:
The outer ring has two integral flanges and the inner ring one integral flange and one non-integral flange in the form of a loose flange ring. The bearings can be used as locating bearings, i.e. they can provide axial location for a shaft in both directions.
RN type:
No outer ring and the inner ring two integral flanges.
NN type:
NN type bearing without ribs on outer ring,there is a wall in the midel of between both sides of inner ring. It can make shaft
relative bearing between the axial displacement generated in both directions.
Designation Principaldimensions Basicloadratings Speedratings
dynamic static Referencespeed Limitingspeed
Fw[mm] D[mm] C[mm] C[kN] C0[kN] [r/min] [r/min]
RNU202ECP 19.3 35 11 12.5 10.2 22000 26000
RNU203ECP 22.1 40 12 20 14.3 19000 22000
RNU2203ECP 22.1 40 16 27.5 21.6 19000 22000
RNU203TN9 22.9 40 12 11.7 9.5 19000 22000
RNU204ECP 26.5 47 14 28.5 22 17000 19000
RNU204 27 47 14 14.7 12 16000 19000
RNU2304ECP 27.5 52 21 47.5 38 15000 18000
RNU304 28.5 52 15 20.5 16.6 15000 18000
RNU205ECP 31.5 52 15 32.5 27 15000 16000
RNU2205ECP 31.5 52 18 39 34 14000 16000
RNU305 35 62 17 28.6 24.5 12000 15000
RNU206ECP 37.5 62 16 44 36.5 13000 14000
RNU2206ECP 37.5 62 20 55 49 13000 14000
RNU1007ECP 42 62 14 41.5 38 11000 13000
RNU306 42 72 19 36.9 33.5 10000 12000
RNU207ECJ 44 72 17 56 48 10000 12000
RNU207ECP 44 72 17 56 48 11000 12000
RNU2207ECJ 44 72 23 69.5 63 10000 12000
RNU2207ECP 44 72 23 69.5 63 11000 12000
RNU307ECP 46.2 80 21 75 63 9500 11000
RNU208ECP 49.5 80 18 62 53 9500 11000
RNU2208ECJ 49.5 80 23 81.5 75 9500 11000
RNU2208ECP 49.5 80 23 81.5 75 9500 11000
RNU308ECJ 52 90 23 93 78 8000 9500
RNU308ECP 52 90 23 93 78 8000 9500
RNU1009ECP 52.5 75 16 52 52 9000 11000
RNU209ECP 54.5 85 19 69.5 64 9000 9500
RNU2209ECP 54.5 85 23 85 81.5 9000 9500
RNU1010ECP 57.5 80 16 53 56 8000 9500
RNU309ECP 58.5 100 25 112 100 7500 8500
RNU2210ECP 59.5 90 23 90 88 8500 9000
RNU1011 64.5 90 18 41.5 41.5 7500 9000
RNU310ECJ 65 110 27 127 112 6700 8000
RNU310ECP 65 110 27 127 112 6700 8000
RNU211ECJ 66 100 21 96.5 95 7500 8000
RNU211ECP 66 100 21 96.5 95 7500 8000
RNU2211ECP 66 100 25 114 118 7500 8000
RNU212ECJ 72 110 22 108 102 6700 7500
RNU212ECP 72 110 22 108 102 6700 7500
RNU2212ECP 72 110 28 146 153 6700 7500
RNU1014ML 80 110 20 64 67 6000 11000
RNU1016ECM 91.5 125 22 112 127 5300 6000
RNU216ECP 95.3 140 26 160 166 5300 5600
RNU1017MA 96.5 130 22 78 86.5 5000 7500
RNU2217ECP 100.5 150 36 250 280 4800 5300
RNU220ECJ 119 180 34 285 305 4000 4500
RNU220ECP 119 180 34 285 305 4000 4500
RNU2319ECML 121.5 200 67 530 585 3600 6300
RNU1024ML 135 180 28 153 183 3600 6300
RNU226ECM 153.5 230 40 285 305 4000 4500
RNU324ECJ 154 260 55 610 620 2800 3200
RNU1030ML 169.5 225 35 228 290 2800 5000
RNU236ECMA 217 320 52 720 850 2200 3600
RNU236ECML 217 320 52 720 850 2200 3600
