Ground Machined Alloy Steel Plates Inconel 722 High Stanadard

Categories Alloy Steel Plates
Brand Name: ANSTEEL,TISCO,BAOSTEEL,PANGANGGROUP
Model Number: Inconel alloy 722
Certification: SGS,TUV,BV,ISO,MTC
Place of Origin: China
MOQ: 1000kg
Price: 80000-85000 USD/Ton
Payment Terms: T/T
Supply Ability: 100000KGS/Month
Delivery Time: Ex-stock for delivery: 5-7days Production lead time: 50-60 days
Packaging Details: Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name:: Inconel alloy 722 Alloy Steel Plates
Grades: Inconel alloy 722
Surface: Black,Bright,etc
Profile: Sheets Plates,etc
Price Term: CIF,CFR,Ex-work,FOB, DDU,etc
Processing methods: Ground,Machined,etc
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Ground Machined Alloy Steel Plates Inconel 722 High Stanadard

Inconel alloy 722 Alloy Steel Plates Inconel 722 Alloy Plates Inconel 722 Alloy


Description


Our company provides Inconel alloy 722 Grinding Alloy Steel Plates Inconel 722 Annealed Alloy Plates Inconel 722 Solution Treated Alloy.

All of Inconel alloy 722 Grinding Alloy Steel Plates Inconel 722 Annealed Alloy Plates Inconel 722 Solution Treated Alloy conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.


  • Material:Metal,Inconel alloy 722 Alloy Steel Plates Inconel 722 Alloy Plates Inconel 722 Alloy
  • Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm

  • Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm

  • Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)

  • Length: Fixed length or random length or based on the customer's special requirement.

Products Details


Inconel alloy 722 Grinding Alloy Steel Plates Inconel 722 Annealed Alloy Plates Inconel 722 Solution Treated Alloy

Chemical Composition (weight%):C (%): ≤ 0.08
Mn (%): ≤ 1.00
Si (%): ≤ 0.70
P (%)≤: 0.035
S (%)≤: 0.010
Cr (%): 14.0 ~ 17.0
Ni (%): 70.0 Min
Ti (%): 2.00 ~ 2.75
Al (%): 0.40 ~ 1.00
Fe (%): 5.00 ~ 9.00
Co (%): ≤ 1.00
Cu (%): ≤ 0.50
Mechanical Properties Under
Final Heat Treatment:
Form: plate, sheet, strip
Tensile strength, σb/MPa: 860
Yield strength, σ0.2/MPa: -
Elongation, δ(%): 40.0
Reduction of area, ф(%): -
Hardness (HB): HRC23 min.


Applications:


Inconel alloy 722 Grinding Alloy Steel Plates Inconel 722 Annealed Alloy Plates Inconel 722 Solution Treated Alloy


Mechanical parts - bolt and nut, fastener
Gas turbine blade
Fuel nozzle,etc


Inconel alloy 722 Grinding Alloy Steel Plates Inconel 722 Annealed Alloy Plates Inconel 722 Solution Treated Alloy


FAQ


Q: How do you control the quality?


A: We have professional inspectors to analyze the chemical composition of Inconel alloy 722 Grinding Alloy Steel Plates Inconel 722 Annealed Alloy Plates Inconel 722 Solution Treated Alloy and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.


Packing method

Wooden Pallet BOX,based on the customer's special requirement,etc
