Home > Steel Round Bars >

1.4301 DIN EN X5CrNi18-10 Stainless Steel Flat Bar Peeled

Categories	Stainless Steel Flat Bar
Brand Name:	PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number:	DIN EN X5CrNi18-10,1.4301
Certification:	SGS,TUV,BV,ISO,MTC
Place of Origin:	China
MOQ:	Negotiations
Price:	Negotiations
Payment Terms:	T/T
Supply Ability:	30000KGS/Month
Delivery Time:	Ex-stock for delivery: 3-7 days Production lead time: 50-60days
Packaging Details:	Wooden Pallet BOX
Product Name:	DIN EN X5CrNi18-10,1.4301 Stainless Steel Flat Bar
Grades:	DIN EN X5CrNi18-10,1.4301
Processing methods:	Cold working,Machined,Ground,Peeled,etc
Surface:	Grinding Centreless Ground Rrough Turned,etc
Profile:	Forging Parts,Sheets Plates,Flat Bar,etc
Price Term:	Ex-work,FOB,CIF,CFR,etc

Contact Now

Add to Cart

Company Info.

Mianyang Baoheng New Material Technology Co.,Ltd

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

1.4301 DIN EN X5CrNi18-10 Stainless Steel Flat Bar Peeled

DIN EN X5CrNi18-10 1.4301 Stainless Steel Flat BarX5CrNi18-10 Flat Bar 1.4301 Bar

Description

Our company provides DIN EN X5CrNi18-10 1.4301 Polished Stainless Steel Flat Bar X5CrNi18-10 Hot rolled steel products Flat Bar 1.4301 Hot rolled Bar.

All of DIN EN X5CrNi18-10 1.4301 Polished Stainless Steel Flat BarX5CrNi18-10 Hot rolled steel products Flat Bar 1.4301 Hot rolled Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.

Material:Metal,Stainless Steel Flat Bar,DIN EN X5CrNi18-10 1.4301.
Shape:Stainless Steel Flat Bar.
Square bar / Flat bar: 3mm to 800mm
Length: Fixed length or random length or based on the customer's special requirement.

Products Details

DIN EN X5CrNi18-10 1.4301 Polished Stainless Steel Flat BarX5CrNi18-10 Hot rolled steel products Flat Bar 1.4301 Hot rolled Bar.

Chemical Composition (weight%):	C (％): ≤ 0.07
	Si (％): ≤ 1.00
	Mn (％): ≤ 2.00
	P(％): ≤ 0.045
	S (％): ≤0.015
	Cr (％): 17.5 ~ 19.5
	Ni (％): 8.00 ~ 10.50
	Mo (％): -
	N (％): ≤0.11
Mechanical Properties Under Room Temperature :	Condition: solution treatment
	Thickness/mm:160
	Tensile strength, σb/MPa: 500~700
	Yield strength, σ0.2≥/MPa: 190
	Elongation, δ5≥(％): 45/35
	Reduction of area, ψ≥(％): 60
	Impact strength, Akv≥/J: 100/60/40
	Hardness HBS30: 215max
Mechanical Properties Above Room Temperature :	Hot forming temp/℃: 1200 ~ 900
	Heat treatment temperature and cooling methods\|annealing: -
	Heat treatment temperature and cooling methods\|quenching: 1000~1100 air/water cooled
	Heat treatment temperature and cooling methods\|tempering: -
	Condition: solution
	High temperature yield strength σ0.2/MPa≥/MPa,at below temp/℃\|100: 155
	High temperature yield strength σ0.2/MPa≥/MPa,at below temp/℃\|200: 127
	High temperature yield strength σ0.2/MPa≥/MPa,at below temp/℃\|300: 110
	High temperature yield strength σ0.2/MPa≥/MPa,at below temp/℃\|400: 98
	High temperature yield strength σ0.2/MPa≥/MPa,at below temp/℃\|500: 92

Applications:

DIN EN X5CrNi18-10 1.4301 Polished Stainless Steel Flat BarX5CrNi18-10 Hot rolled steel products Flat Bar 1.4301 Hot rolled Bar.

Medical equipment
Chemical equipments
Mechanical parts used in the condition of corrosion resistance
Bolt and nut
Pressure vessel

Equivalent Grade

DIN EN X5CrNi18-10 DIN EN 10088-1 2014

1.4301

DIN EN X5CrNi18-10 1.4301 Polished Stainless Steel Flat BarX5CrNi18-10 Hot rolled steel products Flat Bar 1.4301 Hot rolled Bar.

FAQ

Q: How do you control the quality?

A: We have professional inspectors to analyze the chemical composition of DIN EN X5CrNi18-10 1.4301 Polished Stainless Steel Flat BarX5CrNi18-10 Hot rolled steel products Flat Bar 1.4301 Hot rolled Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one.

Q: Do you accept customization?

A: Yes. If you have special requirements for products or packaging, we can make them for you.

Q: Can you accept trial orders?

A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.

Q: How do I get samples?

A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
