| Categories | Stainless Steel Sheets Plates |
|---|---|
| Brand Name: | PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL |
| Model Number: | ASTM 309HNb,UNS S30941 |
| Certification: | SGS,TUV,BV,ISO,MTC |
| Place of Origin: | China |
| MOQ: | Negotiations |
| Price: | Negotiations |
| Payment Terms: | T/T |
| Supply Ability: | 100000KGS/Month |
| Delivery Time: | Ex-stock for delivery: 3-7 days Production lead time: 45-55days |
| Packaging Details: | Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement |
| Product Name: | ASTM 309HNb UNS S30941 Stainless Steel Sheets Plates |
| Grades: | ASTM 309HNb,UNS S30941 |
| Processing methods: | Machined,Cold working,Ground,Peeled,etc |
| Surface: | Black,Bright,Centreless Ground,Rrough Turned,etc |
| Profile: | Forging Piece,Forging Parts,Flat Bar,Sheets Plates,etc |
| Price Term: | Ex-work,FOB,CIF,CFR,etc. |
ASTM 309HNb UNS S30941 Stainless Steel Sheets Plates ASTM 309HNb
S30941 Sheets Plates
Description
Our company provides ASTM 309HNb Hot Rolled UNS S30941 Forged Stainless Steel Sheets Plates ASTM 309HNb S30941 ESR refined Sheets Plates.
All of ASTM 309HNb Hot Rolled UNS S30941 Forged Stainless Steel Sheets Plates ASTM 309HNb S30941 ESR refined Sheets Plates conform to Military standard, nuclear power. 100%
Ultrasonic test SEP 1923 /GB/T 4162 /ASTM E2375 /SAE AMS 2154 /EN
10228-3.
Square bar / Flat bar: 3mm to 800mm
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
Forging piece: stepped shafts with flanks / cubes /discs /slugs /tubes /donuts /other different shapes based on OEM.
Products Details
ASTM 309HNb Hot Rolled UNS S30941 Forged Stainless Steel Sheets Plates ASTM 309HNb S30941 ESR refined Sheets Plates
| Chemical Composition (weight%): | C (％): 0.04 ~ 0.10 |
| Si (％): ≤0.75 | |
| Mn (％): ≤ 2.00 | |
| P (％)≤: 0.045 | |
| S (％)≤: 0.030 | |
| Cr (％): 22.0 ~ 24.0 | |
| Ni (％): 12.0 ~ 16.0 | |
| 10×C%≤(Nb+Ta)≤1.10 | |
| Mechanical Properties Under Final Heat Treatment: | Form: Plate,sheet,strip |
| Tensile strength, σb/MPa: 515 | |
| Yield strength, σ0.2/MPa: 205 | |
| Elongation, δ(％): 40.0 | |
| Reduction of area, ф(％): - | |
| Hardness | HRB: 95 | |
| Cold bending property: N | |
| Hardness (HBW): 217 |
Heat treatment is only suitable for specific grades of stainless steel. When heat treating a stainless the hardening temperatures, including rate of heating, cooling and soaking times will vary due to several factors.
Applications:
ASTM 309HNb Hot Rolled UNS S30941 Forged Stainless Steel Sheets Plates ASTM 309HNb S30941 ESR refined Sheets Plates
Mechanical parts used in the condition of corrosion resistance,
Chemical equipment,
Bolts and nuts,
Pressure vessel,
etc
ASTM 309HNb Hot Rolled UNS S30941 Forged Stainless Steel Sheets Plates ASTM 309HNb S30941 ESR refined Sheets Plates
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical
composition of ASTM 309HNb Hot Rolled UNS S30941 Forged Stainless Steel Sheets Plates ASTM 309HNb S30941 ESR refined Sheets Plates and test the finished products in strict accordance
with the standards stipulated in the contract. In this process, the
inner and outer surfaces, the appearance of both ends, set length,
bending, outer diameter and Wall thickness will be checked one by
one. You can rest assured that all products you receive from us are
reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1000KG.If you want to place an order as the
start of our cooperation, we can accept smaller quantities at the
first time. Of course, after the start, We will have more stable
and long-term cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
FedEx/DHL/UPS accounts can be used for sampling, and the
transportation cost is borne by you.
|
