12v 20ah Gel Rechargeable Sealed Battery For Electric Bike

12v 20ah Gel Rechargeable Sealed Battery For Electric Bike

>Characteristics

♦ Gelled electrolyte made by mixing sulfuric acid with silica fume
♦ The electrolyte is gel like ,immobile and does not leak ,enabling uniform reaction of each part of the plate .
♦ High rate discharge performance due to tight assembly technology
♦ Strong heat dissipation and wide operating temperature range
♦ Avoid acid mist being separated out , environment friendliness
♦ Efficient venting system release excessive gas automatically

>Specification

Battery Model No.		FBR12-100
Nominal Voltage		12V
Capacity (25ºC)	20HR(5.25V)	100Ah
	10HR(5.25V)	76Ah
	1HR(4.80V)	60.9Ah
Dimension	Length	330±2mm
	Width	171±2mm
	Height	214±2mm
	Total height	220±2mm
Approx. Weight		29.5kg±4%
Terminal type		F14
Internal resistance (Fully charged,25ºC)		Approx 4.5mΩ
Capacity affected by temperature(20HR)	40ºC	102%
	25ºC	100%
	0ºC	85%
	-15ºC	65%
Self-discharge (25ºC)	3month	Remaining Capacity:91%
	6month	Remaining Capacity:82%
	12month	Remaining Capacity:65%
Nominal operating temperature		25ºC±3ºC(77ºF±5ºF)
Operating temperature range	Discharge	-15ºC-50ºC(5ºF-122ºF)
	Charge	-10ºC-50ºC(14ºF-122ºF)
	Storage	-20ºC-50ºC(-4ºF-122ºF)
Float charging voltage (25ºC)		13.5 to 13.8V Temperature compensation:-18mV/ºC
Cyclic charging voltage (25ºC)		14.5 to 15V Temperature compensation:-30mV/ºC
Max charging current		30A
Max discharging current		800A(5sec.)
Designed floating life(20ºC)		10years

>Structure and composition

>Application

It is widely used in communication equipment, aviation signal, railway signal,alarm and safety system,

instrument and instrument system,solar energy systems, marine and RV etc.

>Constant Current Discharge Characteristics(A,25ºC)

F.V/Time	10min	15min	30min	60min	2h	3h	4h	5h	8h	10h	20h
9.6V	218	167	101	60.7	36.4	25.9	21.0	18.0	12.3	10.2	5.39
9.9V	211	163	98	60.6	36.2	25.8	20.8	17.8	12.2	10.1	5.37
10.2V	202	158	95	59.2	35.9	25.7	20.6	17.7	12.1	10.0	5.36
10.5V	194	153	93	58.0	35.4	25.5	20.5	17.6	12.0	10.0	5.33
10.8V	182	143	89.5	56.1	34.5	24.6	20.0	17.1	11.9	9.9	5.30

>Constant Power Discharge Characteristics(Watt,25ºC)

F.V/Time	10min	15min	30min	60min	2h	3h	4h	5h	8h	10h	20h
9.60V	2347	1840	1125	703	422	305	246	212	146	121.6	64.5
9.90V	2278	1796	1102	693	420	303	245	211	145	120.7	64.4
10.2V	2185	1730	1069	675	416	301	243	208	144	120.2	64.3
10.5V	2090	1671	1042	660	410	299	241	207	143	119.7	64.2
10.8V	1973	1582	1004	640	399	291	235	201	139	118.9	63.5

>Workshop scene

>FAQ

Q1: How to choose the right battery?

A1: Tell us your demand, then our sales will recommend a suitable battery for you.

Q2: Do you have any MOQ limit?

A2: Yes, we have MOQ for mass production, it depends on the different model numbers.

50-500pcs sample order is available. for sample checking is available.

Q3: Is it OK to print my logo on the product?

A3: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q4: How to solve the technical problem?

A4: 24 hours after-service consultancy just for you and to make your problem to solve easily.

Q5: What certificate your company have?

A5: ISO 9001, ISO 14001, OHSAS 18001, CE, UL, IEC 61427 test report, Patent for gel technology and other Chinese honor.

Q6: What is your warranty time for VRLA battery ?

A6: It depends on battery capacity, depth of discharge, and battery usage.

Please kindly contact us for accurate information based on detailed requirements.
