0.18mm Aluminium Strip Coil 5052-H32 1100-H14 8011/H22

Categories Aluminum Steel Coil
Brand Name: Sylaith
Model Number: 1100 1200 8011
Certification: ISO 9001
Place of Origin: China
MOQ: 1 Ton
Price: Negotiable
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Ton Per Year
Delivery Time: 7-14 days
Packaging Details: Standard seaworthy package
Type: Aluminum Coil
Thickness: 0.2-6.0mm
Inner Diameter: 75, 150, 200, 300, 505mm etc.
Processing Service: Bending, Decoiling, Welding, Punching, Cutting
Specification: 0.18mm x 105mm
Surface: emboss,mirror plane,oxidation
Cutting Type: Laser Cutting;Water-Jet Cutting;Flame Cutting
Model NO.: 1100 1200 8011
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

0.18mm Aluminium Strip Coil 5052-H32 1100-H14 8011/H22

Variety 8011/H22 0.18mm Aluminum Steel Coil Different Size Alloy Coil With Variety Surface


Product Description:


Aluminum has a series of more than any other non-ferrous metals, steel, plastic and wood more superior characteristics, such as such as the density is small, only 2.7 g/cm3, which is about 1/3 of the copper or steel;Good corrosion resistance and weatherability;Good plasticity and processing performance;Good thermal conductivity and electrical conductivity;Good low temperature resistance, high reflectivity and surface properties of light waves;Nonmagnetic;Basic non-toxic;Sound-absorbing sex;Good resistance to acid;Resistance to radiation performance is good;Elastic coefficient;Good mechanical properties;Excellent casting performance and welding performance;Good impact resistance.In addition, the high temperature properties of aluminum, formability, cutting machining, riveting and surface processing performance is good.


Product
Variety 8011/H22 0.18mm Aluminum Steel Coil Different Size Alloy Coil With Variety Surface
Thickness(mm)
0.15mm-6.0mm / 6.0mm-25.0mm or as your requirements
Width(mm)
8mm-2000mm or as your requirements
Standard
GB, JIS, DIN, ASTM
Surface treatment
Mill, Brushed, Mirror, Embossed, Sandblasted, etc
Temper
O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H38 H114/H194, etc.
Type
coil/sheet/strips/plate
Coil ID75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable
Coil OD1700mm max.
Coil weight1000-5000kgs
Package
Standard export package,such as wooden Pallet or as required.


Mechanical Property:


Alloy
Temper
Mechanical performance under room temperature
Tensile (Mpa)Elongation (e%)Erichson (IE,mm)
1100
1200
8011
O80~110≥ 20≥ 6.0
H22100~135≥ 16≥ 5.5
H24115~145≥ 12≥ 5.0
H26125~160≥ 8≥ 4.0
H18≥ 160≥ 1-

No.Item IndexTechnique Index
1Film Thickness1.0~2.0 um (single side average thickness)

2

Hydrophile
Primary contact anglePrimary contact angle ≤ 10°
Continuous contactContinuous contact ≤ 20°

3

Adherence
Erichson test (press deeply to 5mm): no peeling
Gridding test(100/100): no plunger separation
4Corrosion ResistanceR.N ≥ 9.5 Salt spray test (72 hours)
5Alkali ResistanceDipped in 20% NaOH in 20 ºC for 3 minutes, absolutely no blister
6Impregnant ResistanceSamples weight loss 1%

7

Heat Resistance
Under 200 ºC, for 5 minutes, performance and colour unchanged
Under 300 ºC, for 5 minutes, the coating film becomes a little yellow
8Oil proofDip in volatile oil for 24 hours, no blisters on the coating film
9Odor of the coating filmNo odor
10Abrasion to mouldSame as ordinary aluminium foil

Product Details:




Certification:



Packaging & Shipping:



FAQ:


Q1: ARE YOU FACTORY OR TRADER?
A1: Sylaith Special Steel is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.

Q2: HOW TO GET A SAMPLE?
A2: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.

Q3: HOW TO VISIT YOUR FACTORY?
A3: Most of the main cities have flights to Shanghai; you can take flight to Shanghai Putong/Hongqiao International Airport.
If you come from Hongkong, it will take 2 hours by flight (every day 5 flight around noon time).
