| Categories | Stainless Steel Round Bar |
|---|---|
| Brand Name: | PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL |
| Model Number: | 15-5PH, ASTM XM-12, UNS S15500 |
| Certification: | SGS,TUV,BV,ISO,MTC |
| Place of Origin: | China |
| MOQ: | Negotiations |
| Price: | Negotiations |
| Payment Terms: | T/T |
| Supply Ability: | 90000KGS/Month |
| Delivery Time: | Ex-stock for delivery: 3-7 days Production lead time: 50-60days |
| Packaging Details: | Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement |
| Product Name: | 15-5PH Stainless Steel Round Bar |
| Grades: | 15-5PH, ASTM XM-12, UNS S15500 |
| Processing methods: | Shot blasted,Cold working,Machined,etc |
| Surface: | Black,Bright,Centreless Ground,etc |
| Profile: | Round Bar,Sheets Plates,Forging Piece,etc |
| Price Term: | Ex-work,FOB,CIF,CFR, DDU,etc |
15-5PH Stainless Steel Round Bar ASTM XM-12 Bar UNS S15500 Steel
Description
15-5PH Stainless Steel Round Bar ASTM XM-12 Bar UNS S15500 Steel is
a martensitic, precipitation-hardening material with chromium,
nickel and copper. 15-5PH Stainless Steel Round Bar ASTM XM-12 Bar
UNS S15500 Steel is often a first choice in the aerospace industry
for fasteners and structural components. 15-5PH Stainless Steel
Round Bar ASTM XM-12 Bar UNS S15500 Steel is further strengthened
by a low temperature heat treatment which precipitates a copper
containing phase in the alloy. 15-5 PH is able to meet the
stringent mechanical properties required in the aerospace and
nuclear industries.
All of 15-5PH Stainless Steel Round Bar ASTM XM-12 Bar UNS S15500 Steel conform to Military standard, nuclear power. 100% Ultrasonic test
ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Square bar / Flat bar: 3mm to 800mm
Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
Products Details
15-5PH Stainless Steel Round Bar ASTM XM-12 Bar UNS S15500 Steel
| Chemical Composition (weight%): | |
| C (％): ≤ 0.07 Si (％): ≤ 1.00 Mn (％): ≤ 1.00 P (％)≤: 0.040 S (％)≤: 0.030 Cr (％): 14.0 ~ 15.5 Ni (％): 3.50 ~ 5.50 Mo (％): - Cu (％): 2.50 ~ 4.50 Nb+Ta (%): 0.15 ~ 0.45 | |
| Mechanical Properties Under Final Heat Treatment: | |
| Form: Bar, forge piece Condition: H900 Tensile strength, σb/MPa: 1310 Yield strength, σ0.2/MPa: 1170 Elongation, δ (％): 10.0 Reduction of area, ψ (％): 35 Harndess: HRC: ≥ 40 | |
| Form: Bar, forge piece Condition: H925 σb/MPa: 1170 σ0.2/MPa: 1070 δ (％): L-10.0 ψ (％): L-38.0 Hardness HRC: ≥ 38 | |
| Form: Bar, forge piece Condition: H1025 σb/MPa: 1070 σ0.2/MPa: 1000 δ (％): 12.0 ψ (％): 45 Hardness HRC: ≥ 35 | |
| Form: Bar, forge piece Condition: H1075 σb/MPa: 1000 σ0.2/MPa: 860 δ (％): 13.0 ψ (％): 45.0 Hardness HRC: ≥32 | |
| Form: Bar, forge piece Condition: H1100 σb/MPa: 965 σ0.2/MPa: 795 δ(％): 14；10 ψ(％): 45；29 HRC: ≥31 |
Applications:
15-5PH Stainless Steel Round Bar ASTM XM-12 Bar UNS S15500 Steel
used most often in the Marine gas turbine compressor sections,
Hallow shafts, Paper mill equipment, Engine parts, Aircraft
components, Gears, Fittings and fasteners, Nuclear reactor
components.
Equivalent Grade
15-5PH, ASTM XM-12, UNS S15500
15-5PH Stainless Steel Round Bar ASTM XM-12 Bar UNS S15500 Steel
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical
composition of 15-5PH Stainless Steel Round Bar 15-5PH Stainless Steel Round Bar
ASTM XM-12 Bar UNS S15500 Steel and test the finished products in strict accordance with the
standards stipulated in the contract. In this process, the inner
and outer surfaces, the appearance of both ends, bending, set
length, outer diameter and Wall thickness will be checked one by
one. You can rest assured that all products you receive from us are
reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
Packing method
Wooden Pallet BOX,Standard Seaworthy Package,based on the customer's special requirement,etc
|
