| Categories | Stainless Steel Flat Bar |
|---|---|
| Brand Name: | PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL |
| Model Number: | ASTM Grade 422, AISI 422, UNS S42200 |
| Certification: | SGS,TUV,BV,ISO,MTC |
| Place of Origin: | China |
| MOQ: | Negotiations |
| Price: | Negotiations |
| Payment Terms: | T/T |
| Supply Ability: | 110000KGS/Month |
| Delivery Time: | Ex-stock for delivery: 3-7 days Production lead time: 50-60days |
| Packaging Details: | Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement |
| Product Name: | ASTM Grade 422 Stainless Steel Flat Bar |
| Grades: | ASTM Grade 422, AISI 422, UNS S42200 |
| Processing methods: | Ground,Peeled,Cold working,Machined,etc |
| Surface: | Rrough Turned,Grinding,Centreless Ground,etc |
| Profile: | Round Bar,Sheets Plates,Forging Piece,etc |
| Price Term: | Ex-work,FOB,CIF,CFR, DDU,etc |
ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200
Description
ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 is a
hardenable, martensitic stainless steel with exceptional creep
rupture properties between 600-1200°F. Depending on the form,
section, and application involved, this stainless steel can be
heat-treated to different high strength levels. ASTM Grade 422
Stainless Steel Flat Bar AISI 422 UNS S42200 acquires high
mechanical properties through heat treatment and possesses good
oxidation and scaling resistance properties.
All of ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 conform to Military standard, nuclear power. 100% Ultrasonic test
ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
Products Details
ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200
| Chemical Composition (weight%): |
| C (％): 0.20 ~ 0.25 Si (％): ≤ 0.50 Mn (％): 0.50 ~ 1.00 P (％)≤: 0.030 S (％)≤: 0.025 Cr (％): 11.0 ~ 13.5 Ni (％): 0.50 ~ 1.00 Mo (％): 0.90 ~ 1.25 W (％): 0.90 ~ 1.25 V (%): 0.20 ~ 0.30 Cu (%): ≤ 0.50 |
| Mechanical Properties Under Final Heat Treatment: |
| Conditon of delivery: annealed Tensile strength, σb ≥/MPa: - Yield strength, σ0.2 ≥/MPa:- Elongation, δ ≥(％): - Reduction of area, ф ≥(％): - Hardness | HRS: ≤ 248 Condition of delivery: + T Tensile strength, σb ≥/MPa: - Yield strength, σ0.2 ≥/MPa:- Elongation, δ ≥(％): - Reduction of area, ф ≥(％): - Hardness | HRS: ≤285 Condition of heat treatment: HT 1022℃ ~ 1050℃ air or oil cooled, ≥620℃ X 2H, tempered Tensile strength,σb ≥/MPa: 965 Yield strength, σ0.2 ≥/MPa: 760 Elongation,δ ≥(％): 13.0 Reduction of area, ф ≥(％): 30.0 Hardness | HRS: 302 ~ 352 Condition of heat treatment: H 1022℃ ~ 1050℃ air or oil cooled, ≥677℃ X 2H, tempered Tensile strength,σb ≥/MPa: 825 Yield strength, σ0.2 ≥/MPa: 585 Elongation,δ ≥(％): 15.0 Reduction of area, ф ≥(％): 35 Hardness | HRS: 241 ~ 285 |
Applications:
ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 used
most often in the Aircraft parts, Steam and gas turbine components,
Compressor and turbine wheels, High heat components, Thermal
engines components.
Equivalent Grade
ASTM Grade 422 AISI 422 UNS S42200
ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical
composition of ASTM Grade 422 Stainless Steel Flat Bar AISI 422 UNS S42200 and test the finished products in strict accordance with the
standards stipulated in the contract. In this process, the inner
and outer surfaces, the appearance of both ends, bending, set
length, outer diameter and Wall thickness will be checked one by
one. You can rest assured that all products you receive from us are
reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
Packing method
Wooden Pallet BOX,Standard Seaworthy Package,based on the customer's special requirement,etc
|
