Mobile Stage Indoor Rental LED Screen P3.91 500x500 Cabinet SMD2020 Full Color

Categories Indoor Full Color LED Display
Brand Name: SCXK
Model Number: SMD P3.91
Certification: CB/CE/ROHS/FCC/ISO/UL
Place of Origin: CHINA
MOQ: 16 sqm
Price: negotiation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 6500 sqm month
Delivery Time: 5-13 working days
Packaging Details: wooden case,flight case,it is up to you.
resolution: 3840hz
brightness: 1500-4500cd
cabinet size: 500x500mm and 500x1000mm
led lamp: nationstar
control card: novastar ,linsn
warranty: 5 years
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Mobile Stage Indoor Rental LED Screen P3.91 500x500 Cabinet SMD2020 Full Color

P3.91 indoor/outdoor rental led screen led video wall panel pantalla led screen 500*1000mmP2.6 P2.9 P3.91 led display screen


Features:

1. The new structure design enables diversified installation to meet the hanging-up and stacking requirements,
can be applied to achieve a variety of different occasions to meet various application requirements.
2. User-friendly design, more convenient installation, more efficient and secure; High strength, high toughness, and deformation; More reliable cabinet patchwork and cable connection,
3. Cabinets adopt rapid assembling sets, Which can be beautiful but also a real rapid disassembling.


Product specification

SMD P3.91
Lamp size2121
Resolution/mm3.91
Pixel configurationRGB 3 in 1
Pixel density/pixels/m²64510/m²
Module resolution64x64
Module size/mm250x250
View distance≥2m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>8000cd/㎡
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 14 bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
Driving modeConstant driving current
Scanning mode1/8
Frame rate60Hz
Refresh frequency>4200Hz
Control modeComputer synchronous
Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡<1000W
Average power:/㎡<280W
Self-check technologyLED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoringRemote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)storing:10-95%


Product Overviews

ItemsIndoor Led display:
P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10
Outdoor Led display:
P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
Materialsteel,aluminum ,die casting aluminum
Payment
terms
30% deposit before production, 70% balance before shipping
T/T
Western Union
Packing:Standard Export Carton with fully Polyfoam or Pearl Wool
Flight case;
Anti-shaking wooden case
Shipping:5 to 7 working days upon receiving deposit payment
After-Sales-Service:Lifetime with professional engineer support for free.
Within 5 year, supply spare parts for free if has quality problem
( not by man-made damage)
Using RangeShopping mall,bank,bus station, train station,
center of downtown, airport, school, factory, bus, taxi,and so on.

Our case


1.Smd led display module & cabinet is manufactured by using best quality material,we make the module and cabinet by ourselves.
2.Clear picture without flicker and distortion.No light leakage trouble.

3.The final products feature supreme quality and offers best outputs.
4.High refresh rate and gray scale ensures the picture quality remains seamless.
5. Ultra-thin cabinet, the whole cabinet is made of aluminum alloy or magnesium alloy material, Faster and easier installation.
FAQ
Q1:Are you a manufacturer or trading company?
A1:We are a Professional OEM/ODM manufacturer which has specialized in led display industry for 10 years.
Q2:What can you from us?
A2:LED modules,led screen,led display serie product.
Q3:How does your factory do regarding quality control?
A3: We focus on every detail,Our factory has gained ISO9001, ISO14001, CE, RoHS ,FCC,CCC authentication.
Q4:What is your MOQ?
A4:Any quantity is acceptable for your order. And the price is negotiable for large quantity.
