Ground Surface Structural Steel Flat Bar DIN EN C30 1.0528 Grade

Categories Structural Steel Flat Bar
Brand Name: PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number: DIN EN C30, 1.0528
Certification: SGS,TUV,BV,ISO,MTC
Place of Origin: China
MOQ: Negotiations
Price: Negotiations
Payment Terms: T/T
Supply Ability: 80000KGS/Month
Delivery Time: Ex-stock for delivery: 3-7 days Production lead time: 45-55days
Packaging Details: Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name: DIN EN C30 Structural Steel Flat Bar
Grades: DIN EN C30, 1.0528
Processing methods: Cold working,Machined,etc
Surface: Grinding,Centreless Ground,etc
Profile: Flat Bar, Forging Piece,etc
Price Term: Ex-work,FOB,CFR, etc.
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Ground Surface Structural Steel Flat Bar DIN EN C30 1.0528 Grade

DIN EN C30 Structural Steel Flat Bar 1.0528 Ground


Description


DIN EN C30 Structural Steel Flat Bar 1.0528 Ground is Open steel for general engineering purposes. Non-alloy quality and special steels.

All of DIN EN C30 Structural Steel Flat Bar 1.0528 Ground conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.


  • Material:Metal, DIN EN C30 Structural Steel Flat Bar 1.0528 Ground
  • Shape:Structural Steel Flat Bar
  • Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm

  • Round bar / Wire rod (Diameter): 5.5mm to 800mm


Products Details


DIN EN C30 Structural Steel Flat Bar 1.0528 Ground


Chemical Composition (weight%):

C(%): 0.27~0.34
Si(%): ≤0.40
Mn(%): 0.50~0.80
P(%)≤: 0.045
S(%)≤: 0.045
Cr(%): ≤0.40
Mo(%): ≤0.10
Ni(%): ≤0.40
Other: Cr+Mo+Ni≤0.63%

Mechanical Properties Under
Final Heat Treatment:
Annealed hardness | HBS: 170 max.
Tensile strength,σb/≥ MPa: 600 ~ 750
Yield strength, σ0.2/≥ MPa: 400
Elongation, δ ≥(%): 18
Impact, ≥J /Akv: 30


Applications:


DIN EN C30 Structural Steel Flat Bar 1.0528 Ground used most often in the Seawater handling equipments Oil and gas production equipments,etc


DIN EN C30 Structural Steel Flat Bar 1.0528 Ground


FAQ


Q: How do you control the quality?


A: We have professional inspectors to analyze the chemical composition of DIN EN C30 Structural Steel Flat Bar 1.0528 Ground and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.



Packing method

Wooden Pallet BOX,Standard Seaworthy Package,based on the customer's special requirement,etc
