Automatic Self-Test
Once switched on, AHANVOS systems perform a comprehensive internal
test
Real-time Monitoring and Instance Response System for Tissue
Density
This proprietary technology delivers optimal clinical effects
through continuous synchronization of current and voltage. It
samples the current and voltage 450,000 times per second which
enables it to respond to tissue impedance changes in less than 10
milliseconds, which ensuring the machine achieves optimum energy
output levels quicker and more accurately – ensuring that only the
precise voltage needed is safely delivered to each tissue type.
Ligasure Vessel Sealing (Seal-Safe)
With above mentioned Real-Time and instance response system, it
enables permanent sealing up blood vessels with a diameter up to
7mm with this technology under bipolar coagulation (Seal-safe
modes).
Endoscopic Vessel Sealing (Endo-Safe)
Vessel sealing under water with endoscopic instrument
Automatic Start /Stop
Under Bipolar cut and coagulation modes, user can choose Pedal
control or Automatic control, under Automatic control.
Memory Records Features (Optional)
Memory program that allows customize settings for different
interventions and surgeons. Now total from 0-10 memory locations
can be available for user- defined settings, which make AHANVOS a
versatile, indispensable companion in HF surgery.
Compatible with Argon Plasma Coagulation System
Compatible with Argon Generator, non-contact tissue, which can have
very good effect for digestive surgery.
Optimum Smoke Evacuation System
AHANVOS Electrosurgical unit can be integrated with smoke
Evacuation system, which will automatically trigger the smoke
evacuation when energy is activated.
Application of Use
General Surgery; Ligation Surgery; Gastroenterology Dermatology;
Vascular Surgery; Obstetrics and Gynecology
Heart/Thoracic Surgery; ORL/ENT; Minimally Invasive Surgery (MSI)
Cerebral surgery; Neurosurgery, Orthopedics & Plastic Surgery;
Trans Urethral Resection (TUR) and etc.
Technical Specifications
Out put Frequency: 512KHz
Power Supply: 100-240V / 50-60Hz
Dimension: 34*16*47
Weight: 8.5KG
High Frequency Leakage:
Monopolar: < 150mA
Bipolar: < 60mA
Low Frequency Leakage:
Normal Polarity, Intact chassis ground: <10μA
Normal Polarity, Ground open: < 50μA
Reverse Polarity, Ground open: < 50μA
Sink Current, 140V Applied, All inputs: < 50μA
