Outdoor Waterproof Street Light IP66 Led Street Lamp Adjustable Bracket IK08

Categories Outdoor LED Street Lights
Brand Name: Die-casting Man
Model Number: SL04
Certification: CE
Place of Origin: CHINA
MOQ: 1 PCS
Price: USD17~19/PCS
Supply Ability: 30pcs/per day
Delivery Time: 25 days
Packaging Details: PE bag+bubble+carton
Material: Hign pressure die-cast aluminum
Input Wattaage: 30~150W
Color Temperature: 3000/4000/6500K
LED Lifetime: 50000h
Protection Grade: IP66 IK08
Temperature of working condition: -40~50℃
Power Factor: PF≥0.95
Housing Calor: Dark Grey/Black/Light Grey (availabel on request)
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Outdoor Waterproof Street Light IP66 Led Street Lamp Adjustable Bracket IK08

Economic street lamp IP66 waterproof Nema Zhaga available Outdoor led street IK09 light


Prodcut Specification


Material:Hign pressure die-cast aluminumWattage:30~150W
IP:66CRI:≥70
Color Temperature:3000/40000/6500KInput Voltage:AC90 - 265V
Frequency Range:50 - 60HzWorking Ambient Temperature:-40℃ - 50℃
Working Ambient Humidity:20% - 90%RHLED Lifetime:50000h


Part Number:SL04
Production Lead Time:7-30 Days
MOQ:1 PCS
Shipping:EXW / FOB NINGBO
Finish Color:Double gray;Sandy black;

Product Datasheet
Item No.SL04-30W-SSL04-50W-SSL04-6OW-SSL04-80W-MSL04-100W-MSL04-120W-LSL04-150W-L
Power30W50W60W80W100W120W150W
Lumen Efficiency130lm/w130lm/w130lm/w130lm/w130lm/w130lm/w130lm/w
Lumen3900lm6500lm7800lm10400lm13000lm15600lm19500lm
Product Size (mm)456x122x13456x122*13456x122*13536x166x13536x166*13618x461x13618x461*13
Electrical Data
Working VoltageAC100-265V 50/60Hz
LED:Lumileds / Epistar / SANAN
CCT3000K, 4000K, 5000K ,6000K
CRIRa>70 (standard)/ Ra>80
Driverlocal
THD<15%
Power Factor(PF)PF>0.9
IP RatingIP66
IK Rating1K09
Holder50mm/B60mm (standard)
Body MaterialHign pressure die-cast aluminum
Housing CalorDark Grey/Black/Light Grey (availabel on request)
Cover MaterialUV-resistant Polycarbonate
Working Environment-20 ~+50 , 10%~90%RH
Lifespan L70 at 25> 50,000hrs
Mounting TypeSide entry or Vertical pole mounted ±15°
Dimmable1-10V Dimming /Timer Dimming
Protecdion ClassClass I (standard) / Class
StandardsCE, RoHS, ENEC, CB, LM79. LM80, TM-21, IP66, IK09
Available on requestNEMA socket (3/5/7pins), ZHAGA socket. Short cap, Photocell., Motion sensor, NTC. OLC, DALI Dimming
Reasonable toleranceWatt: ±10%,CCT:±500K, Lumen efficiency: ±5%

Is there anything else you want to know about this lamp?


1. Q:What is the waterproof rating?

A: It’s can pass IP66

2. Q:How many years of warranty do you promise?

A: We guarantee the housing for 5 years.for the whole lamp,The warranty of electrical parts is depends on the warranty time of different driver brand.

3. Q:What is the grade of your powder coating?

A: Normal is C2 grade,but If the customer has special request,such as used at the seaside,in this case,we can use phosphating with Akzo powder to reach higher levels,like C3,C4.

4. Q:What's the packing you use?

A: Our packing is PE bags with foam and carton box,we will ensure it safe.

5. Q:What is your usual lead time?

A: 25 days for regular products, 10 days extra for special requirements.

6. Q:Do you sell only whole lamps?Or I can just buy the empty housing?

A: It’s up to you,we can also sell empty housing,even you just by the die-casting housing without powder coating is also no problem.

7. Q:What brand of driver do you use?

A: The brand we usually use is Inventronics,Sosen these China local brand,and PHILIPS,MEANWELL these international brand,Customers can also specify brands,it’s no problem.

8. Q:About the powder coating,i have a question,What colors do you usually use?Can we customize the color?

A: The colors we usually use are black and gray,you can also customize other color,just tell us the RAL number,we will according the RAL number to do the powder coating.

9. Q:Ok,that’s good,So if I want to specify a color,will you charge extra cost?

A: will not,but we will require MOQ500 pcs.

10. Q:ok,last question,Do you accept OEM?

A: Of course we can,we have own die-casting machine and mould design team,must be able to meet your requirements,and we already have a lot of OEM customers.
