220AC Surface SMD Component Mounting Machine 20000 Pcs/H

Categories	SMT Pick And Place Machine
Brand Name:	HWGC
Model Number:	HW-T8-80F
Certification:	CE
Place of Origin:	China
MOQ:	1
Price:	usd+15000+pieces
Payment Terms:	T/T,
Supply Ability:	30+Pieces+Month
Delivery Time:	5-8work days
Packaging Details:	Export wooden package
Placement rates:	13000CPH
Accuracy:	± .001” (0.02mm）
Voltage:	220AC
Smallest Component Capability:	0201
Vision System:	HWGC Vision
Vibratory Feeders:	Loose, tube, stick (frequency & amplitude control)

Contact Now

Add to Cart

Company Info.

Beijing Huaweiguochuang Electronic Technology Co., Ltd.

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

220AC Surface SMD Component Mounting Machine 20000 Pcs/H

Mounting speed of various components(resistance,capacitance,chip)20000 pcs/h.

After buying our machines, your engineers can go to our company or it is so easy to operate. We have English user manual and guide video to teach you how to use the machine. The user manual will come with the machine together.

porduct description

The HW-T8-80F is our most popular model with Vision. The HW-T8-80F offers technologically advanced features with 260mm x 400mm work area, 80 single feeder positions (up to 120 feeders using bank feeders) where quick setup, easy of operation and high reliability are paramount.

Products Description

Specification
Number of Placement Heads	8(high-accuracy)
Number of iC Trays	96
Number of Feeders	120(subject to 8mm feeder)
Positioning Accuracy	0.01mm
Repeated Mounting Accuracy	0.02mm
Range of Mounting Speed	20000-26000Pcs/h
Applicable Components	resistor.capacitor.chip.lamp bead etc.
Supported Maximum Area of PCB	340*560mm
Feeders	NXT electric feeder,vibrating feeder, IC tray etc
Recognition Devices	mark camera x2,fast recognition camera x8. high-precision camera x1
Maximum Height of Applicable Components	≤20mm
Recognition Methods	simultaneous recognition and picking with eight heads
PCB Convey Mode	three-stage entry automatic connection from left to right, automatic PCB positioning
Mark Positioning	manual/automatic
Programming Method	automatic programming after manually importing files of PCB coordinates

Our Advantages

1.120pcs material stations -- can meet the mounting requirements of
various materials and various specifications and packages of the
product.

1) 120pcs 8mm material stations support NXT electric feeder, 12mm,
16mm, 24mm, 32mm and 44mm NXT electric feeder,,vibration feeder and
IC trays.

2)NXT electric platform specification: 8mm-44mm NXT electric
feeder, electric feeder stable feeding, high precision, long
service life.

2.8 groups of independent mounting heads - 8 groups of mounting
heads are distributed with different nozzles, which are suitable
for the mounting requirements of products with more specifications.

1) 8 groups of mounting heads can realize the double arms and four
heads pick simultaneously,pick up the material at same time, The
picking efficiency is improved greatly.

2)The mounting head can rise and fall independently, rotate from 0
to 360 degrees, and mount up to 20 mm components.

3)The z-axis can rise and fall independently according to the
thickness of the components,For the resistance and capacitance
components, the mounting head can realize the fly visual
identification, High components can be mounted at reduced speed.

4)It can meet the requirements of different sizes of components,
different specifications and different packages, achieve diversity,
one-time placement.

3.The comprehensive efficiency is 20000pcs/h, and the maximum
efficiency is 26000pcs/h.

1)Mounting speed of various
components(resistance,capacitance,chip)20000 pcs/h.

2)Only capacitance or resistance or LED lamp mounting speed is
26000pcs/h.

Feeders

Yamaha Pneumatic feeder and Electricial feeder were adopted, sizes include 8mm, 12mm, 16mm, 24 mm, 32mm and 44mm.
