6 Ton Corrugated Roof Panel Roll Forming Machine PPGI Ibr Sheeting Equipment

Categories Metal Roofing Machine
Brand Name: DLY
Model Number: tile 1250
Certification: CE
Place of Origin: China
MOQ: 1 set
Price: Negotiable
Payment Terms: T/T
Supply Ability: 30sets/month
Delivery Time: 40 days
Packaging Details: naked or wooden
Product name: Roof Tile Making Machine
Tile type: Roof Tiles Making Machine
Warranty: 14 months
Shaft material: high grade #45 steel
Weight: 6T
Use: Roof,wall
Color: blue/ According to the clients need
Usage: Roof Tile Panel,wall decoration
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

6 Ton Corrugated Roof Panel Roll Forming Machine PPGI Ibr Sheeting Equipment

380V 1250mm Metal Roof Tiles Making Machine For Construction Industry


1. Brief Introduction of Roof Tile Making Machine


This machine takes GI/PPGI as raw material, through a series steps and can produce the metal roofing sheets. The inverter controls the motor speed, the PLC system controls length and quantity automatically, therefore, the machine achieves a continuous automatic production, which is the ideal equipment for cold roll forming industry.

2. Roof Tile Making Machine specifications


Serial Number
Item
Parameter
Remark
Applicable material
Type
GI/PPGI
Thickness
0.3-0.7MM
Yield strength(Mpa)
G245-550
Main performance parameters
Forming speed(M/MIN)
0-10m/m
Machine size(L×W×H)
8*1.5*1.5
base on machine design
Power supply(KW)
7.5+5.5
Main Motor &Hydraulic Motor
MACHINE COMPONENTS FOR Step tile forming machine
Name
Model/name
Quantity
Technical description
1.Decoiling system
Hydraulic decoiler or Manual
1 set
Capacity: Max. 5Ton,hydraulic control steel coil inner bore expanding, shrinkage and stop.
2.Forming machine
Material Guiding System
1 set
For feeding in a right position no Deviation.
Precutting Device
1 set
Pre-cutting or motoraized cut
Main Roll Forming Machine
1 set
About 18 steps base on the design
3.Cutting system
Hydraulic Cutting
Precutting and postcutting both.
4.Hydraulic system
Hydraulic Station
1 set
Providing the power of cutting.
5.Control system
PLC Control System
1 set
PLC control system, encoder positioning and cut-to-length automatically, touch screen operating.
6.Racking system
Exit rack
2 PC
no power.

3. Customer Feedback

Our Tile roofing machine produce perfect profile, have good connection and received high comment from our clients.



4. FAQ


What is your machine warranty?

some quick-wear parts will be container together with machine.

if some parts damaged within one year, we will send new one to you for free, just freight up to you.
