| Categories | Steel Flange |
|---|---|
| Brand Name: | YUHONG SPECIAL STEEL |
| Model Number: | ASTM B564 HASTELLOY C276 |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Place of Origin: | China |
| MOQ: | 1 PC |
| Price: | NEGOTIABLE |
| Payment Terms: | L/C, T/T |
| Supply Ability: | ACCORDING TO CLIENT'S REQUIREMENT |
| Delivery Time: | 20-30 DAYS |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Standard: | ASTM B564 / ASME SB564 |
| Material Grade: | HASTELLOY C276 Flange, UNS (N10276), DIN (2.4819) |
| Product Name: | Alloy Flange |
| Dimensions: | ANSI/ASTM B16.5, B16.7 SERIES A&B, B16.48 |
| Flange Type: | SORF Rasied Face (RF) |
| Class/Pressure: | 150#,300#,600#,900#,1500#,2500#,PN6,PN10,PN16,PN25,PN40,PN64,etc |
| Size: | 1/2" To 48" |
| Company Info. |
| Yuhong Group Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
ASTM B564 UNS N10276 Hastelloy C276 Nickel Alloy Flange SORF Flange
Hastelloy C-276 has a excellent resistance to localized corrosion, stress corrosion cracking, oxidizing and reducing media, which is suit for a wide variety of chemical process environments, including ferric and cupric chlorides, hot contaminated media (organic and inorganic), formic and acetic acids, seawater and brine solutions. Meanwhile, Hastelloy C276 is the few kinds of material that can withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide.
It is a solid solution strengthened nickel-molybdenum-chromium alloy with a small amount of tungsten. Alloy C-276 exhibits excellent corrosion resistance in a variety of harsh environments and media. Like many other nickel alloys, it is ductile, easily formed and welded.
What are the characteristics of Hastelloy C276?
1. Excellent corrosion resistance in reducing environments
2. Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
3. High nickel and molybdenum contents providing good corrosion resistance in reducing environments
4. Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
5. Resistance to localized corrosion such as pitting and stress-corrosion cracking
6. One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide
N10276 flange types
WN brida forjada, bridas de cuello de soldadura – WNRF
-N10276 Welding Neck Flange(WNF) & Long Welding Neck Flange(LWNF)
-N10276 Slip-on Flange(SOF)
-Lap Joint Flange(LJW)
-N10276 bind Flange
-Socket Welding Flange (SWF)
-Threaded Flange(THW)
-Plate Flange
ASTM/ASME/ANSIB16.5, B16.47, ASME/ANSI B16.48 flange
slip on flange, Weld Neck Flange ,Threaded Flange Blind Flange,
Equivalent Grades for Hastelloy Alloy C276 Tubes
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | - | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Chemical Composition
| Hastelloy C276 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.010 max | 15.00 – 17.00 | 1.00 max | 0.08 max | 4.00 – 7.00 | 0.04 max | 0.03 max | 2.5 max | 14.50 – 16.50 |
Mechanical Properties
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | Psi – 1,15,000 , MPa – 790 | 40 % |
Hastelloy Slip On Flange Specification
| Specification : | Hastelloy C276 Flanges |
| Production Process: | Heat Treated, Machined, Forged |
| Coating Flange Faces : | Zinc Plated, Yellow Transparent, Anti-rust Paint, Cold and Hot Dip Galvanized, Oil Black Paint |
| Standards: | ISO Flanges, GOST Flanges, UNI Flanges, AWWA Flanges, MSS SP44 Flanges, ASME B16.5 Flanges, ASME B16.38 Flanges, EN-1092 Flanges, BS10 Flanges, DIN Flanges, PN Flanges, JIS Flanges, ASME B16.47 (Series A, Series B) Flanges |
| Pressure Rating Table: | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Connect Type: | RF, FF, RTJ, LMF, SMF, LJF |
| Size Chart : | 1/2″ (15 NB) To 48″ (1200NB) |
| Common Types of Flange : | Flanges 150 LB WNRF Class 300 RTJ 600# BLRF Class 900 SORF |
| Supporting Flange Material: | Gasket, Flange Bolts, Ring Joint |
| Application: | Nuclear Power Plant Chemical Industry Fabrication Industry Natural Gas Industry Oil And Gas Industry Water Pipeline Industry |
| Design For Size: | PN, DIN, JIS, ANSI, EN, ASA, ASME, BS |
| Flange Machining Equipment: | Bending machine, Pushing Machine, Sand-blasting machine, Press machine, electric bevelling machine etc |
Applications & Uses of Hastelloy Alloy Flanges
Although there are several variations of the Hastelloy nickel alloy, Hastelloy C-276 is by far the most widely used.
Alloy C-276 is widely used in the most severe environments such as chemical processing, pollution control, pulp and paper production, industrial and municipal waste treatment, and recovery of sour natural gas.
Hastelloy C276 Flange are mainly used in Oil & Gas, Chemical, Nuclear power (mostly seamless), Power, Bitumen upgraders,
Petrochemicals and acids, Heavy oil refineries, Gas, ,Construction, Shipbuilding industries, Metallurgy&others.
|
