| Categories | Stainless Steel Sheet Plate |
|---|---|
| Place of Origin: | Jiangsu, China, China |
| Brand Name: | None |
| Model Number: | LG101 |
| Packaging Details: | Export packing |
| MOQ: | 10 Kilograms |
| Price: | $2.30/Kilograms 10-999 Kilograms |
| Grade: | 304 |
| Standard: | ASTM, ASTM |
| Length: | 2438mm, 2438mm |
| Thickness: | 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.2, 1.5, 2.0, 2.5, 3.0, 4.0, 5.0, 6.0, 8.0, 10, 12, 14, 16, 18, 20, 22, 24, 25, 26, 28, 30, 35, 40, 45, 50, 55, 60, 65, 70, 80 |
| Width: | 1219mm, 1219mm |
| Type: | Plate |
| Application: | Power equipment unit, Power plant, etc., Power equipment unit,Power plant,Electrical Equipment Company,etc. |
| Tolerance: | None |
| Processing Service: | Bending, Welding, Decoiling, Punching, Cutting |
| Steel Grade: | 304N, 310S, S32305, 410, 316Ti, 316L, 321, 410S, 347, 430, 309S, 304, 439, 409L, 304L, S32101, 904L, 304J1, 317L, 2205, C276, 2507, S32168, 201, 321H, 347H |
| Surface Finish: | 2B |
| Delivery Time: | within 7 days |
| The Material: | 304 |
| Quality Grade: | The real thing |
| City of warehouse: | Wuxi, jiangsu province |
| Type of Goods sold: | The spot |
| Species: | Plate |
| Port: | In Shanghai port |
High Quality Professional Manufacturers Customized ASTM 304 Stainless Steel Plate
| Surface Finish | Definition | Application | |
| 2B | Finished by heat treatment , picking or equipvalent cold rolling , followed by skin pass to obtain adequate luster surface. | With bright and smooth surface ,easy for further grinding to obtain brighter surface ,suitable for medical instruments ,milk containers ,tableware and so on. | |
| BA | Bright heat treatment after cold rolling. | Structual members .etc.kitchen utensil ,cutlery ,eleltric applicances ,medical instruments ,building decorations ,etc. | |
| NO.3/NO.4 | Polished with No.150-240 abrasives. | Milky food processing equipment , medicalinstruments ,building decorations. | |
| HL | Finshed by polishing with abrasives of suitable grain size to obtain continuous streaks. | Building decorations ,such as elevators ,escalators ,door etc. | |
| 6K/8K | A mirror-like reflective surface ,which is obtained by polishing with successively finer abrasives and buffing extensively with all gritlines are removed. | Buliding entrances,bulkding column casting ,elevator's wall doors ,counters,sculptures etc. | |
| Stainless Steel Coil/Sheet/Plate Information | |||||||||||
| Technique | Surface Finish | Grade Series | Thickness(mm) | Width(mm) | Application | ||||||
| Main Dimension | |||||||||||
| 20-850 | 1000 | 1219 | 1240 | 1250 | 1500 | Petro-chemical industry,Tanks Construction material | |||||
| Hot Rolled | No.1 / 2E | 201/202/ 304 | 2.2-12.0 | √ | √ | √ | √ | √ | |||
| Cold Rolled | 2B | 201/304 | 0.25-3.0 | √ | √ | √ | √ | √ | √ | ||
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | ||||||
| No.4 / Hairline Mirror / Linen SB | 201/304 | 0.22-3.0 | √ | √ | √ | √ | √ | ||||
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | √ | |||||
| BA | 201/304 | 0.2--1.8 | √ | √ | √ | √ | |||||
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | ||||||
| 2BA | √ | √ | √ | √ | |||||||
| Chemical composition and mechanical properties of stainless steel coils | |||||||||
| Grade | Chemical Composition (%) | Mechanieal Performece | |||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Hardness | |
| 201 | ≤0.15 | ≤1.00 | 5.5/7.5 | ≤0.060 | ≤0.030 | 3.5/5.5 | 16.0/18.0 | - | HB≤241,HRB≤100, HV≤240 |
| 304 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.0/11.0 | 18.00/20.00 | - | HB≤187,HRB≤90,HV≤200 |
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.00/14.00 | 16.0/18.0 | 2.00/3.00 | HB≤187, HRB≤90 HV≤200 |
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.00/14.00 | 16.0/18.0 | 2.00/3.00 | HB≤187, HRB≤90 HV≤200 |
| 410 | ≤0.15 | ≤1.00 | ≤1.25 | ≤0.060 | ≤0.030 | ≤0.060 | 11.5/13.5 | - | HB≤183, HRB≤88 HV≤200 |
| 430 | ≤0.12 | ≤1.00 | ≤1.25 | ≤0.040 | ≤0.03 | - | 16.00/18.00 | - | HB≤183, HRB≤88 HV≤200 |
Place of Origin | China |
The Material | 304 |
Standard | ASTM |
Quality Grade | The Real Thing |
City of Warehouse | Wuxi, jiangsu province |
Type of Goods Sold | The spot |
Thickness | 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.2, 1.5, 2.0, 2.5, 3.0,
4.0, 5.0, 6.0, 8.0, 10, 12, 14, 16, 18, 20, 22, 24, 25, 26, 28, 30,
35, 40, 45, 50, 55, 60, 65, 70,80mm |
Length | 2438mm |
Width | 1219mm |
Species | Plate |
Application | Power equipment unit, Power plant Electrical, Equipment Company,
Machinery factory, Thermal power plant, Automobile manufacturing,
Construction engineering, Pipeline engineering, Building
decoration, shipyard |
|
