NJ Big Size Single Row Cylindrical Roller NJ230 Chrome Steel Crankshaft Bearings 150x270x45 mm

Categories Cylindrical Roller Bearing
Brand Name: NSK
Model Number: NJ230
Certification: ISO9001:2008
Place of Origin: Japan
MOQ: 1 pcs
Price: negotiation
Payment Terms: T/T or western Union or PayPal
Supply Ability: 3,000pcs per month
Delivery Time: 3 working days after received your payment
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Structure: Cylindrical
Type: Roller
Material: Chrome steel
Application: Vibration machinary,CNC machine and so on
earing crankshaft bearings width: 45 mm
Weight: 11.9 KG
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

NJ Big Size Single Row Cylindrical Roller NJ230 Chrome Steel Crankshaft Bearings 150x270x45 mm

150x270x45mm NJ big size cylindrical roller bearing NJ230 Chrome steel cylindrical roller bearing crankshaft bearings

All sizes of roller bearings NJ230 Chrome steel cylindrical roller bearing crankshaft bearings :
  • N Series - Bearings of N design are single row cylindrical roller bearing and have two fixed ribs on the inner ring that retain the rollers and cage and one smooth outer ring. This design allows an axial displacement in certain limits, of the shaft in relation to the housing. Therefore, N Series rolling bearings are used in non-locating bearing units. Also, the N Series bearings have virtually no thrust capacity.
  • NU Series - Are single row cylindrical roller bearings and have two fixed ribs on the outer ring and one smooth inner ring. This design allows an axial displacement in certain limits, of the shaft in relation to the housing. Therefore, NU Series rolling bearings are used in non-locating bearing units. Also, the NU Series bearings have no virtually thrust capacity.
  • NN Series - Bearings of NN design are double row cylindrical roller bearing and have three fixed ribs on the inner ring that retain the rollers and cage and one smooth outer ring. This design allows an axial displacement in certain limits, of the shaft in relation to the housing. Therefore, N Series rolling bearings are used in non-locating bearing units. Also, the NN Series bearings have no virtually thrust capacity.

There are different types designated NU, NJ, NUP, N, NF for single-row bearings, and NNU, NN for double-row bearings depending on the design or absence of side ribs. AST’s cylindrical roller bearings come in the following series with various cage designs and Metric dimensions:


All sizes of roller bearings NJ230 Chrome steel cylindrical roller bearing crankshaft bearings

All sizes of roller bearings NJ230 Chrome steel cylindrical roller bearing crankshaft bearings specification :

d150
D270
B45
rsmin3
Ew242
Fw182
Mass (KG)11.9
Cr (KN)440
Cor (KN)585
Limiting Speed4500
Bearing CodeNJ230E
D1Min164
D1Max179
D2Min184
D3Min196
D4Max256

Stock series bearing

NJ205ENJ205EMNJ205MNJ205
NJ206ENJ206EMNJ206MNJ206
NJ207ENJ207EMNJ207MNJ207
NJ208ENJ208EMNJ208MNJ208
NJ209ENJ209EMNJ209MNJ209
NJ210ENJ210EMNJ210MNJ210
NJ211ENJ211EMNJ211MNJ211
NJ212ENJ212EMNJ212MNJ212
NJ213ENJ213EMNJ213MNJ213
NJ214ENJ214EMNJ214MNJ214
NJ215ENJ215EMNJ215MNJ215
NJ216ENJ216EMNJ216MNJ216
NJ217ENJ217EMNJ217MNJ217
NJ218ENJ218EMNJ218MNJ218
NJ219ENJ219EMNJ219MNJ219
NJ220ENJ220EMNJ220MNJ220
