30w-240w solar light led Street Light Waterproof High Lumen Aluminum Pcb 150lm/w high efficiency

Categories Waterproof LED Street Light
Brand Name: Coursertech
Model Number: JMHX-004
Place of Origin: CHINA
MOQ: 100
Price: 60USD
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20000 sets a month
Delivery Time: 30 work days
Packaging Details: CARTON
Product name: 004 led street lights
Watt: 30W,60W,120W,160W,240W
CCT: 3000-4500K
Lumen: 140lm/w
Application scenarios: Yards, driveways, streets, highways
Installing Size: Φ61mm
Voltage: 100-265V
Power: 30-250W
Life time: 80000HRS
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

30w-240w solar light led Street Light Waterproof High Lumen Aluminum Pcb 150lm/w high efficiency

Minimum 30w Maximum 240w Classic Ip65 Led Street Lights Applied To The Street


Energy saving is the energy saved under the same average illuminance, the average illuminance can not only be the ground average illuminance! The light intensity of the space has a good prediction for the vehicles coming in the distance, so as to prevent traffic accidents. But the LED street lamps installed in China all sacrifice illumination to achieve energy saving.

Heat dissipation of LED street lamps

Street lamps are used outdoors, to be waterproof and dustproof, so the lamps must be sealed, sealed after the temperature of the water vapor in the lamps in extreme climate conditions is more than 100 degrees, LED in such a high temperature environment continuous work, LED street lamps if the heat dissipation is not done, the lamps are very easy to bad or serious light failure. The heat dissipation problem of domestic high-power LED street lamps has not been completely solved, and the subsequent maintenance cost of the products will inevitably increase.

The penetration ability of LED lights

On rainy and foggy days, LED lighting line is not strong enough to wear fog.

It is easy to attract mosquitoes outdoors

Because mosquitoes are particularly fond of some wavelengths of LED light, there are moths flurping the flame, which will affect its light efficiency.

To sum up: LED, as a new light source, has irreplaceable advantages in replacing incandescent lamps and fluorescent lamps, but there are still some problems in the use of high-power LED street lamps. Radical and comprehensive replacement of LED street lamps (especially on main roads) may cause sequelae. If extreme weather occurs, a large number of lights may be broken or severe light failure, affecting road safety.


NoParameter
/Item No
JMLW150JMLW250
1Rated Power80-150w200-250w
2LED Chip5W/pc5W/pc
3LED Quantity88132
4CCT3500K-4500K3500K-4500K
5VoltageAC100-265VAC100-265V
6Frequrncy Range50-60Hz50-60Hz
7Power factor0.9750.975
8Lumen150lm/w150lm/w
9Total lumen12000lm30000lm
10IPIP65IP65
11Working life>80000HRS>80000HRS
12Environment Temperature-30℃to+65℃-30℃to+65℃
13Light Body materialAluminiumAluminium
14Pole Height10-12m12m
15Installing SizeΦ61mmΦ61mm
16Products Size885*361*166mm1053*379*174mm
17Packing Size900*380*190mm1070*400*180mm
18Net Weight15KG24KG
19Gross Weight16.5KG26KG

Parameter InformationsJMJX-30JMJX-60JMJX-90JMJX-120JMJX-150
Rated Power30W60W90W120W150W
LED Chip3W/pc3W/pc3W/pc3W/pc3W/pc
LED Quantity24487296120
Color Temperature4500-5500K4500-5500K4500-5500K4500-5500K4500-5500K
Input VoltageAC100-260VAC100-260VAC100-260VAC100-260VAC100-260V
Frequency Range50-60Hz50-60Hz50-60Hz50-60Hz50-60Hz
Power Factor>0.97>0.97>0.97>0.97>0.97
LED Luminous Efficiency140lm/w140lm/w140lm/w140lm/w140lm/w
(%)
Lamp's Efficiency
>92%>92%>92%>92%>92%
IP GradeIP65IP65IP65IP65IP65
Working life>80000HRS>80000HRS>80000HRS>80000HRS>80000HRS
Environment Temperature-30℃to+65℃-30℃to+65℃-30℃to+65℃-30℃to+65℃-30℃to+65℃
Light Body materialAluminiumAluminiumAluminiumAluminiumAluminium
Pole Height6m7m9m10m12m
Central Illumination40lux(6m)55lux(7m)48lux(9m)47lux(10m)40lux(12m)
Pole Distance25M35M40M45M50M
Installing SizeΦ61mmΦ61mmΦ61mmΦ61mmΦ61mm
Products Size520*380*120mm600*380*120mm720*380*120mm840*380*120mm960*380*120mm
Packing Size580*445*185mm660*445*185mm780*445*185mm900*445*185mm1020*445*185mm
Net Weight8KG10KG12KG14KG16KG
Gross Weight10KG12KG14KG16KG18KG
