| Categories | Wear Resistance Steel Plate |
|---|---|
| Brand Name: | TONGMAO |
| Model Number: | steel plate |
| Certification: | ISO9001 MTC |
| Place of Origin: | China |
| MOQ: | 10tons |
| Price: | Negotiablle |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500tons/month |
| Delivery Time: | 7-15days |
| Packaging Details: | Standard Packing |
| Standard: | ASTM,AISI,JIS,GB,DIN |
| Length: | 1-12m |
| Grade: | 400 Weldox700 Domex500 Nm360 |
| Width: | 100-300cm or customized |
| Thickness: | 3mm-100mm |
| Name: | abrasion resistant steel plate |
| Standard Grade | DIN : XAR300, XAR400, XAR450, XAR500, XAR600, X120Mn12; 1.3401,
etc... SSAB : WELDOX700, WELDOX900, WELDOX960, etc. NF : FORA400, FORA500; Creusabro4800, Creusabro8000, etc. EN : QUARD400, QUARD450, QUARD500; RAEX320, RAEX400, RAEX500, etc. JIS : JFE-EH360, JFE-EH400, JFE-EH500; WEL-HARD400, WEL-HARD500,etc. GB : NM360, NM400, NM450, NM500, NM550, NM600, etc. |
1.Wear resistant steel plate has high wear resistance and good impact performance. It can be cut, bent and welded. It can be connected with other structures by welding, plug welding and bolt connection. It is time-saving and convenient in the process of maintenance. It is widely used in metallurgy, coal, cement, electric power, glass, mining, building materials, brick and tile and other industries.
| Standard | Grade | C | Mn | Si | Cr | Mo | Yield strength min | Tensile strength min | Elongation% |
| GB/Nm360 | Nm360 | ≤0.25 | ≤1.30 | ≤0.70 | ≤1.4 | ≤0.50 | 1000MPa | 1100MPa | 50 |
| AISI | GB | JIS | DIN | KS | BSEN |
| Nm360 | Nm360 | JFE-EH360 | DILLIDUR 400V | 400 | creusabro 4000 |
2. 400 is a wear-resistant steel plate with a Brinell hardness of
400HB, which has good cold bendability and is mainly used in
anti-wear conditions. 400 has very good weldability.
400 wear-resistant steel application: crusher, sieve plate, feeder,
feeding funnel, elevator, blade plate, conveyor, bucket, cutter
plate, gear, dump truck, scraper, industrial Trucks, rail wagons,
bulldozers, excavators. Slurry pipes, screw conveyors, presses,
etc.
| Country | AR | Sweden | China | Germany |
| Standard | AR | GB/T | XAR | |
| Grade | AR400 | 400 | NM400 | XAR400 |
| Grade | C | Si | Mn≤ | P≤ | S≤ | Cr≤ | Mo≤ | Ni≤ |
| AR400 | 0.12-0.16 | 0.35-0.55 | 1.55 | 0.025 | 0.005 | 0.55 | 0.55 | 1.0 |
| NM400 | 0.20 | 0.70 | 1.6 | 0.025 | 0.01 | 1.4 | 0.5 | 1.0 |
3.Features of DOMEX700 high-strength steel plate:
The welding performance is similar to that of ordinary low carbon steel. The welding wire used is completely different from ordinary welding wire depending on the material. For equal toughness fit, the strength is slightly lower than that of the base metal.
DOMEX700 does not need special measures such as preheating before welding.
Almost forgot the biggest advantage, the yield strength is 700, choose it in the board below 10mm.
The actual machining experience is harder than ordinary steel.
Standard | JIS, AiSi, ASTM, GB, DIN, EN |
Length | 1000mm-custom |
Width | 500-3000mm-custom |
Model Number | 550/500/450/400/360 NM600/500/450/400/360 Ar500/550/400
Xar500/450/400/550 Dillidur500/450/400 Surfacing composite wear resistant steel plate 4+2 6+2 8+2 3+3 4+4 5+5 6+6 7+7 8+8 10+10 Surfacing composite wear resistant steel plate:Support customization |
Certification | ISO |
Tolerance | ±0.01% |
Processing Service | Bending, Welding, Decoiling, Punching, Cutting |
Price Term: | CIF CFR FOB EX-WORK |
MOQ: | 1 TON |
| Payment terms: | TT 30% and the remaining 70% will be paid before delivery. |
FAQ
Can you send products to my country?
Sure, we can. If you do not have your own ship forwarder, we can
help you.
Will you delivery the goods on time?
Yes,we promise to provide best quality products and delivery on
time no matter if the price change lot or not.Honesty is our
company's tenet.
How can I get a quotation from you ?
You can leave us message, and we will reply every message in time.
Or we may talk on line by Trademanager.
And you can also find our contact information on contact page.
How do you make our business long-term and good relationship?
1. We keep good quality and competitive price to ensure our
customers benefit ;
2. We respect every customer as our friend and we sincerely do
business and make friends with them
|
