FESTO ISO cylinder DSBC-40-200-PPVA-N3 1376663 GTIN4052568016746 Pneumatic Air Cylinders

Categories	Pneumatic Air Cylinders
Brand Name:	FESTO
Model Number:	DSBC-40-200-PPVA-N3
Place of Origin:	China
MOQ:	1pc
Price:	EXW USD60-70
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	50 pcs per month
Delivery Time:	10-15 working days
Packaging Details:	plastic bag, carton，OPP bag
Brand:	FESTO
Part no:	1376663
GTIN:	4052568016746
Type:	DSBC-40-200-PPVA-N3
Material bearing:	POM
Material collar screws:	Galvanised steel

Contact Now

Add to Cart

Company Info.

Airwolf Automation

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

FESTO ISO cylinder DSBC-40-200-PPVA-N3 1376663 GTIN4052568016746 Pneumatic Air Cylinders

About product

1.The variants can be configured according to individual needs using a modular product system.

2.Wide range of variants provides high level of flexibility.

3.PPV cushioning: pneumatic cushioning, adjustable at both ends.

4.Extensive range of accessories makes it possible to install the cylinder virtually anywhere.

5.Double-acting.

Technical Data

Stroke	200 mm
Piston diameter	40 mm
Piston rod thread	M12x1.25
Cushioning	Pneumatic cushioning, adjustable at both ends
Mounting position	optional
Conforms to standard	ISO 15552
Piston-rod end	Male thread
Design	Piston Piston rod Profile barrel
Position detection	Via proximity switch
Symbol	00991235
Variants	Piston rod at one end
Mode of operation	Double-acting
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20°C-80°C
Cushioning length	19 mm
Basic weight for 0 mm stroke	740 g
Additional weight per 10 mm stroke	37 g
Type of mounting	Via female thread With accessories Either:
Pneumatic connection	G1/4
Note on materials	RoHS-compliant
Material cover	Die-cast aluminium, coated
Material piston seal	TPE-U(PU)
Material piston	Wrought aluminium alloy
Material piston rod	High-alloy steel
Material piston rod wiper	TPE-U(PU)
Buffer seal material	TPE-U(PU)
Cushioning piston material	POM
Material cylinder barrel	Smooth-anodised wrought aluminium alloy
Material nut	Galvanised steel
Material bearing	POM
Material collar screws	Galvanised steel

Another stroke as follow

Type	Order no	GTIN	Price
DSBC-40-20-PPVA-N3	2123166	4052568251796	USD60-70
DSBC-40-25-PPVA-N3	1376656	4052568016678	USD60-70
DSBC-40-30-PPVA-N3	2123167	4052568251802	USD60-70
DSBC-40-40-PPVA-N3	1376657	4052568016685	USD60-70
DSBC-40-50-PPVA-N3	1376658	4052568016692	USD60-70
DSBC-40-60-PPVA-N3	2123224	4052568251819	USD60-70
DSBC-40-70-PPVA-N3	2123225	4052568251826	USD60-70
DSBC-40-80-PPVA-N3	1376659	4052568016708	USD60-70
DSBC-40-100-PPVA-N3	1376660	4052568016715	USD60-70
DSBC-40-125-PPVA-N3	1376661	4052568016722	USD60-70
DSBC-40-150-PPVA-N3	2123226	4052568251833	USD60-70
DSBC-40-160-PPVA-N3	1376662	4052568016739	USD60-70
DSBC-40-200-PPVA-N3	1376663	4052568016746	USD60-70
DSBC-40-250-PPVA-N3	1376664	4052568231798	USD60-70
DSBC-40-300-PPVA-N3	2123227	4052568251840	USD60-70
DSBC-40-320-PPVA-N3	1376665	4052568016753	USD60-70
DSBC-40-400-PPVA-N3	1376666	4052568231804	USD60-70
DSBC-40-500-PPVA-N3	1376667	4052568016760	USD60-70

Data sheet

Festo is the world's leading manufacturer of pneumatic and electromechanical systems, components and controllers for process control and factory automation solutions, with more than 55 national headquarters in more than 180 countries/regions.

There are so many kinds. Hurry to call me!
