IP65 Outdoor Telecommunication Cabinet Customized Size

Categories Telecommunication Cabinet
Brand Name: LANGJI
Model Number: Telecommunication Cabinet
Certification: ce/Sgs
Place of Origin: China
MOQ: 1pc
Price: USD100-500/pc
Payment Terms: T/T, L/C
Supply Ability: 2000 Unit/Units per Month
Delivery Time: 7-15days
Packaging Details: Wooden box on export pallet or according to customer requirements
Material: Galvanized Steel etc
Features: Waterproof
Dimensions: Standard or Customized
Application: Telecommunication
Cooling system: AC/TEC/Hex
Color: RAL7035 or customized
Certificate: ISO9001/14001
Service: OEM.ODM
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

IP65 Outdoor Telecommunication Cabinet Customized Size

IP65 Customized Size Outdoor Telecommunication Cabinet Outdoor Communication Cabinet​


Feature

Product Name
Outdoor Cabinet
Certification
CE,ISO,RoHS,GS
Structure
Single layer ,Double layer insulation structure
Type
Single cabin,double cabins,tthree cabins optional
Material
Galvanized sheet,201/304/316 Stainless Steel,Aluminum
Doors
Front door,Front and rear door,Panel door,Glass door optional
Thickness
19"rails:2.0mm,outer panel adopt 1.5mm,internal panel adopt 1.0mm. Other option according to customer
Size
1500*800*800mm
Accet Customized size.
Cooling method
AC Fans,DC Fans,AC Air condition,DC Air condition
AC Heat-exchange,DC Heat-exchange.
Heating method
Heater,Heat-exchange ,Air condition
Surface treatment
Painting,plasma electrostatic painting,hot galvanized,powder coating,polishing,atc.
Optional Accessories
Sensors:Door alarm,Temperature Sensor,Hunidity Sensor ,Water Sensor,Smoke alarm,etc.
Cooling device:Fan,Air condition ,Heat exchange.
others:Shelves,Mouitor,PDU,Power supply,Lightning protection,Breakers,Power distribution box,DDF,ODF,Battery,etc.
Package
High quality carton box package.
Export standard carton box+plywood pallet package.
Export standard plywood box package.

The equipment cabinet is designed to house a variety of batteries and equipment, they provide protection from vandalism,dust,rain, snow and dripping water. Airconditioner (options: Heat exchanger/TEC/Fan) is installed on cabinet for keeping a stable temperature inside cabinet so as to increase service life and stability of battery and equipment. It provide a secure thermally managed environment for backup battery systems for telecommunications and cable applications.


Accessory List(options)
No.ItemSpecifications
1FanDC48V, START WORK AT 35°C
2Power Distribution (PDU)GRADE B LIGHTNING PROOF
AC INPUT: 63A/2P *1; AC OUTPUT: 16A/1P*4;
DC OUTPUT: 16A/1P*4 or customer requirement
3Environment Monitoring Unit48VDCCommunication port: RS485, TCP/IP, SNMP optional
4Door SensorMonitor door open status inside cabinet and provide real time alarm.
5Water SensorMonitor water status inside cabinet and provide real time alarm.
6Tilt & Shock SensorMonitor shock status inside cabinet and provide real time alarm.
7Temperature & Humidity SensorMonitor temperature and humidity inside cabinet and provide real time alarm.
8Smoke SensorMonitor smoke status inside cabinet and provide real time alarm.
9Ground BarResistance value: 0.021Ω
10Built-in power supply150A/200A/300A
11PackagingWooden case/Export pallet

Cooling System(Optional)
No.ItemSpecifications
1Air ConditionerAC220V/DC48V, Cooling capacity 300w, 400w, 600w, 800w, 1000w, 1200w, 1500w, 2000w, 2500w, 3000w, 3500w, 4000w; AC380V,5000w
2Heat ExchangerAC220V/DC48V, Heat transfer 80w/k, 100w/k, 120w/k, 150w/k, 200w/k
3Thermoelectric Cooler (TEC)DC48V, Cooling capacity 200w, 300w
4FanDC48V
Product Application
Packing & Delivery
Langji Technology Co., Ltd. was founded in 2009, it is a high-tech enterprise with R&D, manufacturing and sales department. It is located at the coast of Taihu Lake Suzhou city, the registered capital is 50 million RMB. The whole factory covers 5000 square meters and employs about 200 people with an annual sale of nearly 100 million RMB.
Langji company provides full range of temperature control products and solutions for
- Telecommunication
- Data Center
- Base station
- Solar based installations
- Wireless cell sides & switches
- Industry Automation
- Energy Storage
Suzhou Langji Technology Co., Ltd. is always taking the concept of "well-grounded, ambitious and make all efforts to create national brand of precision air conditioner", holding 3 point management strategy that includes technique, force, and service,tracking the market trend and focusing on the development of products. Based on strong technical force, and advanced design ideas,Langji has promoted many models of precision air condition, heat exchanger, and energy-saving products for base station or equipment room, outdoor communication equipment cabinet and thermostatical battery cabinet etc. to meet the diversified needs of the domestic and overseas customers.
Suzhou Langji Technology Co., Ltd. manages the company and production scientifically according to ISO9001 and ISO14001 international management system. The products are certified by CE and CCC, with stable and reliable quality, Langji products are sold in many countries and regions including China, India, Russia, the Middle East, South-east Asia, South America, Africa, Europe and the USA.
