| Categories | Fluid Bed Granulator |
|---|---|
| Brand Name: | SNYNXN |
| Model Number: | FL |
| Certification: | CE ISO GMP |
| Place of Origin: | JIANGSU CHINA |
| MOQ: | 1 SET |
| Price: | NEGOTIABLE |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100 SETS/ YEAR |
| Delivery Time: | 60 DAYS |
| Packaging Details: | Film wrapping, wooden case. |
| Product name: | FL-300 explosion-proof fluid bed granulator |
| Type: | Granulator, fluidized bed granulation machine |
| Function: | granulating & drying, Granulator, food, pharmaceutical, |
| Application: | Powder, Granules, Pharmaceutical, food, Chemical Industrial |
| Capacity: | 3-750kg/batch, 12L-1500L container volume |
| Material: | SUS304, SUS316L, Other, Stainless steel304/316L |
| Temperature: | room temp. - 120 |
| Working Time: | 45-90 min (varies as different raw materials) |
| After sales Service: | Online Support, Engineers available to service machinery overseas |
1 .Fluid bed to achieve fast heat transmission of medium.
2.Seal negative pressure operation, there is no dust.
3. Because of using anti-static material as filter, it is safe in
operation;
4. The equipment has no dead corner so it is easy to clean fully
and there is no cross pollution;
5.It is conformity with the requirements of GMP.
Technical Parameter
| type | 3 | 5 | 30 | 60 | 120 | 200 | 300 | 500 | 1000 | ||
| item | unit | ||||||||||
Container of raw material | diameter | mm | 300 | 400 | 700 | 1000 | 1200 | 1400 | 1600 | 1800 | 2200 |
| volume | L | 12 | 22 | 100 | 220 | 420 | 670 | 1000 | 1500 | 2500 | |
Production capacity | min | kg/batch | 1.5 | 4 | 15 | 30 | 80 | 100 | 150 | 250 | 500 |
| max | kg/batch | 4 | 6 | 36 | 72 | 140 | 240 | 360 | 600 | 1100 | |
| consumption of steam | kg/h | 12 | 23 | 70 | 140 | 211 | 282 | 366 | 465 | 800 | |
amount of compressed air | m3/min | 0.3 | 0.3 | 0.3 | 0.6 | 0.6 | 0.9 | 0.9 | 0.9 | 1.5 | |
| Power of fan | kw | 2.2 | 4 | 5.5 | 11 | 18.5 | 22 | 30 | 45 | 75 | |
| Temperature | ºC | 120°C (Adjustable from ambient to 120) | |||||||||
| Yield | % | >99 | |||||||||
| Option time | min | 1530(depends on material) | |||||||||
| Content at final term. | % | -0.2( depends on material) | |||||||||
| Noise | dB | ≤75 | |||||||||
| Height of main machine | mm | 2100 | 2300 | 2500 | 3000 | 3300 | 3800 | 4000 | 4800 | 6200 | |
Company profile
Division I professional production of various kinds of
pharmaceutical machinery and drying equipment, our products sell
well in over 20 provinces and cities, and exported to America,
Mexico, Spain, Singapore, Russia, belarus, Egypt, South Korea,
Malaysia, the Philippines, the united Arab emirates, Thailand,
Vietnam, Pakistan, India, Iran, South Africa, Algeria, Syria,
Mongolia, Bangladesh and other countries. The company is constantly
updating and developing pharmaceutical machinery, chemical
equipment, drying equipment, mixing equipment, granulator, coater
and sewage treatment equipment and other products. With strict
testing means and a complete set of scientific management
procedures, and through the ISO9001 international quality system
certification, product quality has reached the advanced level at
home and abroad, pharmaceutical machinery products in line with
"GMP standard". Our company tenet: product quality to win with
excellence, sales and service to honesty, the contract to honor the
letter.
Corporate core values
Pay attention to technology creation, improve quality, quality and
service
Corporate mission
Let customers create more value, contribute more wealth to the
society, and establish a respected brand for the country
Talent concept
People-oriented, pay attention to talent, to establish the cradle
of talent to research core technology
Respect employees, identify with employees, give employees a safe
harbor and a stage to show their talent
Business philosophy
Win-win cooperation
FAQ
Q: Delivery period:
A: Around 15-60 days, delivery perious will vary as different types
of machinery,
|
