| Categories | Cable Testing Machine |
|---|---|
| Brand Name: | AI |
| Model Number: | AIC-22060 |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 1 set Dumbbell Shape Die Sample Cutter |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200 sets per month |
| Delivery Time: | 30 days |
| Packaging Details: | Dumbbell Shape Die Sample Cutter packed in Plywood case |
| Test standard: | GB/T 2951.11 |
| Impact stroke: | 110mm |
| Air supply pressure: | 0.8MPa |
| Impact force: | about 1.5T |
| Working bed size: | 140 × 300mm |
| Dumbbell cutter die: | 50×8.5×4mm, 75×12.5×4mm |
| Power supply: | AC220V 50Hz |
| Overall dimension: | 500×560×880mm |
| Air source: | compressed air |
| Color: | White |
| Company Info. |
| Advanced Instruments Co.,Limited |
| Verified Supplier |
| View Contact Details |
| Product List |
Product description:
Dumbbell die sample cutter is used to cut rubber, insulation and
sheath materials, make them to be standard-shaped sample for test.
Allocated with various dumbbell cutter dies for different test
requirements.
Standard:
• GB/T 2951.11-2008
Technical parameters:
• Impact stroke: 110mm
• Air supply pressure: 0.8MPa
• Impact force: about 1.5T
• Working bed size: 140 × 300mm
• International dumbbell cutter die: 50×8.5×4mm, 75×12.5×4mm
• Dumbbell cutter die is able to be customized
Specifications:
• Overall dimensions: 500×560×880mm
• Compressed air(prepared by users)
|
