AMS 5644 Steel Forging Parts UNS S17700 Galvanised Flat Bar

Production Information

AMS 5644 Precipitation Hardening Stainless Steel Alloy.
It is a semi-austenitic and is austenitic when annealed
state and hardened state of martensite. AMS 5644 provides high strength and hardness, excellent fatigue properties, good corrosion resistance and minimal heat treatment distortion. It is easily formed in the annealed state and then hardened
High strength levels are achieved by simple heat treatment at conditions RH 950 and TH 1050.
Excellent mechanical properties at temperatures up to 900ºF (482ºC).

Size Range

Round bar / Wire rod (Diameter):	5.0mm to 1100mm
Square bar / Flat bar:	5.0mm to 1000mm
Forging piece:	Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled:	T6 - 100mm X W10 - 1000mm X L1500-10000mm
Sheet steel via cold rolled:	T0.5 - 4.0mm X W6 - 1000mm X L1000 - 10000mm
Steel strip via cold rolled:	T0.1 - 4.0mm X W5 - 150mm X L (or in coil form)
Length	Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

Grade	AMS 5644 / UNS S17700
standard	SAE AMS 5644E-2017 / ASTM A313/A313M-2018
Chemical Composition (weight%)	C (％): ≤ 0.09 Mn (％): ≤ 1.00 Si (％): ≤ 1.00 P (％)≤: 0.040 S (％)≤: 0.030 Cr (％): 16.0 ~ 18.0 Ni (％): 6.50 ~ 7.75 Al (%): 0.75 ~ 1.50

Mechanical Properties

AMS 5644 Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa:	≥1172
Yield strength,Rp/MPa:	≥965
Elongation/%:	≥6
Reduction of area, ψ/%:	≥25
Impact, KV /J:	--
Annealed hardness HBS:	≤363
