| Categories | Corten Steel Plate |
|---|---|
| Brand Name: | Gnee |
| Model Number: | Corten A / Corten B |
| Certification: | SGS |
| Place of Origin: | Tianjin |
| MOQ: | 5 Ton/Tons |
| Price: | $657.14 / Ton |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 Ton/Tons per Month |
| Packaging Details: | Standard Seaworth Packing |
| Standard:: | AiSi, ASTM, bs, DIN, GB, JIS |
| Grade:: | A588, Q235NH,Q335GNH,SPA-H,09CuPCrNi-A |
| Place of Origin:: | China |
| Brand Name:: | Gnee |
| Type:: | Steel Plate |
| Technique:: | Hot Rolled |
| Surface Treatment:: | clean or as required |
| Application:: | outdoor decoration, railway, tower |
| Width:: | 0.6-3m or as required |
| Length:: | 1-12m or as required |
| Tolerance:: | ±1% |
| Processing Service:: | Bending, Welding, Decoiling, Cutting, Punching |
| Color:: | Customers Samples Color |
| Name:: | weathering steel plate |
| Company Info. |
| Gnee Steel (tianjin) Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
ASTM A242/Corten A /A588 Gr. B/ S355Jowp Corten Steel Sheet Plate Art /Weathered Steel Plate Price Per Kg
| Product Name | Corten Steel Sheets/Steel Plate |
| size | as required |
| Thickness | Cold Rolled : 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.2, 1.5mm Hot Rolled: 1.6, 2.0, 2.5, 3.0, 4.0, 5.0, 6.0, 8.0, 10, 12,
14,16.......40 mm |
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS etc |
| Technique | Hot rolled / cold rolled |
| Application | It is widely used inRailway, bridges, rolling stock, shipping container etc |
| Price Terms | FOB, EXW, CIF |
| Packing | Wooden Pallet or according to customer's requirements |

| %C | %Si | %Mn | %P | %S | %Cr | %Cu | %V | %Ni | Yield | Tensile | Elongation | |
| Corten A | .12 | .25-.75 | .2-.5 | .07-.15 | .03 | .5-1.25 | .25-.55 | .65 | 355MPA | 470-630MPA | 20% | |
| Corten B | .16 | .3-.5 | .8-1.25 | .03 | .03 | .4-.65 | .25-.4 | .02-.1 | .4 | 355MPA | 470-630MPA | 20% |
| ASTM A588 | .19 | .3-.65 | .8-1.25 | .05 | .04 | .4-.65 | .25-.4 | .4 | 340MPA | 480MPA | ||
| ASTM A242 Type 1 | .12 | .75 | 1 | .06-.15 | .03 | .3-1.25 | .25-.55 | .52 | .4 | 355MPA | 510-680 | IMPACT-20/27J |
| S355JOWP | .12 | .75 | 1 | .06-.15 | .035 | .3-1.25 | .25-.55 | N.009 | .4 | 355MPA | 510-680 | IMPACT0/27J |
| Grade | C | Mn | Cr | Si | N | S | Cu | P | Ni | V | ||||||||||
| A588GrA | ≤0.19 | 0.80-1.25 | 0.40-0.65 | 0.30- 0.65 | ≤0.010 | 0.050 | 0.25-0.40 | 0.040 | ≤0.40 | 0. 01 -0. 10 | ||||||||||
| A588GrB | ≤0.20 | 0.75-1.35 | 0.40-0.70 | 0.15- 0.50 | ≤0.010 | 0.050 | 0.20-0.40 | 0.040 | ≤0.50 | 0. 01 -0. 10 | ||||||||||
| A588GrC | ≤0.15 | 0.80-1.35 | 0.30-0.50 | 0.15- 0.30 | ≤0.010 | 0.050 | 0.20-0.50 | 0.040 | 0.25-0.50 | 0.0 1- 0. 10 | ||||||||||

Widely used in a variety of architectural and engineering
structures,such as
1.) metal constructions such as buildings,bridges,ships;
2.) transmission tower, reaction tower;
3.) lifting transportation machinery;
4.) industrial furnace;boilers
5.) container frame, warehouse goods shelves, etc

|
